Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 100mm -
Fork SunTour XCT
-
Groupset Altus, Tourney -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 7005 Aluminum Butted
Suspension Fork
Suntour SF-XCT 100mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Altus SGS
Front Derailleur
Shimano Altus
Shift Levers
Shimano Tourney EZ Fire Integrated
Cassette
Shimano HG30 11-32 8 spd
Crank
42/32/22
Bottom Bracket
FSA
Chain
YBN S8
Pedals
Wellgo LU-A9
Wheels
Front Hub
KT Disc
Rear Hub
KT Disc
Rims
Shining MT-20
Spokes
Stainless 14g
Tires
Vittoria Saguaro 26x2.2
Brakes
Brakes
ProMax Mechanical Disc
Brake Levers
Shimano Integrated
Disk Rotors
ProMax 160mm
Cockpit
Stem
Kona Control
Handlebar
Kona Aluminum Riser
Grips
Kona Mooseknuckle
Headset
CH
Seat
Saddle
Kona XC
Seatpost
Kona Thumb w/offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 14" | 16" | 18" | 20" | 22" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.57 mm | 1.52 mm | 1.5 mm | 1.52 mm | 1.24 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 310 mm | 310 mm | 315 mm |
| Front Center | 620 mm | 650 | 675 mm | 690 mm | 710 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm |
| Stack | 581 mm | 596 mm | 616 mm | 631 mm | 536 mm |
| Reach | 371 mm | 391 mm | 411 mm | 416 mm | 431 mm |
| Top Tube Length | 551 mm | 576 mm | 601 mm | 626 mm | 656 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 71.5 ° | 71 ° |
| Seat Tube Length | 355 mm | 405 mm | 455 mm | 510 mm | 560 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 110 mm | 130 mm | 150 mm | 170 mm | 190 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1051 mm | 1081 mm | 1101 mm | 1121 mm | 1141 mm |
| Bottom Bracket Drop | 38 mm | 38 mm | 33 mm | 33 mm | 28 mm |
| Standover Height | 741 mm | 771 mm | 811 mm | 841 mm | 871 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" |
About this model
Lana’i is a Kona Lanai model. Kona released 14 bikes variations of this model so far.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork
The SunTour XCT is included from the factory. It has a travel distance of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
The wheels on Lana’i are the 26″ aluminum type. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they provide less traction than 29″ wheels do.
Brakes
When you want to stop the bike in time, the brakes are vital. The Lana’i has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
