Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork SunTour XCT
-
Groupset X4, SRAM -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 6016 Aluminum Butted
Suspension Fork
Suntour XCT 100mm
Rear Shock
n/a
Drivetrain
Rear Derailleur
SRAM X4
Front Derailleur
SRAM 3.0
Shift Levers
SRAM X4
Cassette
SRAM PG820 11-32t 8 spd
Crank
22/32/42t
Bottom Bracket
TH 7420
Chain
KMC Z72
Chain Guide
n/a
Pedals
Wellgo Platform
Wheels
Front Hub
Joytech
Rear Hub
Joytech
Rims
Alex TD26
Spokes
Stainless 14g
Tires
Vittoria Saguaro 29x2.2"
Brakes
Brakes
Tektro HDC300
Brake Levers
Tektro HDC300
Disk Rotors
Tektro HDC300 160mm
Cockpit
Stem
Kona Control
Handlebar
Kona XC/BC Riser
Grips
Kona Race Light LOG
Headset
CH
Seat
Saddle
Kona XC
Seatpost
Kona Double Clamp
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 19" | 21" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.64 mm | 1.57 mm | 1.59 mm | 1.56 mm |
| Bottom Bracket Height | 316 mm | 316 mm | 316 mm | 316 mm |
| Front Center | 651 mm | 677 mm | 691 mm | 717 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 86 mm | 87 mm | 86 mm | 86 mm |
| Stack | 633 mm | 643 mm | 661 mm | 680 mm |
| Reach | 387 mm | 410 mm | 417 mm | 436 mm |
| Top Tube Length | 570 mm | 595 mm | 620 mm | 645 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 105 mm | 115 mm | 135 mm | 155 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1093 mm | 1119 mm | 1133 mm | 1159 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 58 mm | 58 mm |
| Standover Height | 772 mm | 801 mm | 832 mm | 866 mm |
| Wheels | 29" | 29" | 29" | 29" |
Model Overview
LAVA DOME completes the Kona Lava model. Kona released 10 bikes variations of this model so far.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
LAVA DOME components
Fork
Kona LAVA DOME 2014 bike is equipped with the SunTour XCT fork, and has 100mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
When it comes to wheels, the LAVA DOME bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The LAVA DOME comes with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
