Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b -
Groupset GRX 800, Shimano -
Suspension Rigid -
Motor Shimano 250W 60Nm mid-drive -
Battery Shimano 504Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
50cm
147cm - 170cm
52cm
157cm - 182cm
54cm
167cm - 188cm
56cm
175cm - 195cm
58cm
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 6061 Aluminum Butted
Suspension Fork
Kona Verso Full Carbon Flat Mount Disc
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano GRX
Front Derailleur
n/a
Shift Levers
Shimano GRX 810
Cassette
Shimano Deore 11-42t 11spd
Crank
Shimano E8000, Direct Mount Samox 38t
Bottom Bracket
n/a
Chain
Shimano 105
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Formula 100x12mm
Rear Hub
Formula 142x12mm
Rims
WTB HTZ i25 TCS 2.0
Spokes
Stainless 14g
Tires
WTB Venture TCS w/ Puncture Protection 650x47c
Brakes
Brakes
Shimano GRX 810
Brake Levers
Shimano GRX 810
Disk Rotors
Shimano RT66 160mm
Cockpit
Stem
Kona Road Deluxe
Handlebar
Kona Road
Grips
Kona Cork Tape
Headset
Orbit 1.5ZS, No.57-T
Seat
Saddle
WTB Volt
Seatpost
TranzX Dropper +RAD Internal w/ Shimano Lever 31.6mm
Motor & Battery
Motor
Shimano E7000 20MPH
Battery
Shimano 504Wh
Remote
Shimano SC-E7000 Display
Charger
Shimano STEPS 2A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 52cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.52 mm | 1.54 mm | 1.57 mm | 1.62 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 271 mm | 271 mm | 273 mm |
| Front Center | 632 mm | 638.7 mm | 642.6 mm | 650.7 mm | 666.4 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 64 mm | 64 mm | 61 mm | 61 mm | 61 mm |
| Stack | 600 mm | 605 mm | 621 mm | 636 mm | 666 mm |
| Reach | 394 mm | 399 mm | 402 mm | 405 mm | 410 mm |
| Top Tube Length | 554 mm | 566 mm | 579 mm | 592 mm | 612 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 455 mm | 490 mm | 510 mm | 540 mm | 550 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 157 mm | 163 mm | 180 mm | 196.5 mm | 230 mm |
| Chainstay Length | 444 mm | 444 mm | 444 mm | 444 mm | 444 mm |
| Wheelbase | 1065 mm | 1072 mm | 1077 mm | 1085 mm | 1101 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 72 mm | 72 mm | 70 mm |
| Standover Height | 737 mm | 762 mm | 784 mm | 808 mm | 828 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 147 cm | 157 cm | 167 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 182 cm | 188 cm | 195 cm | 195 cm |
About this model
Libre EL completes the Kona E Libre model. 3 e-bikes variations carry this model name so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Gravel e-bikes
If you want an acceptable Gravel e-bike you should know that the average price is 3642$. However, you could also get a good Gravel e-bike even if you pay a lower amount than the average price. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
This e-bike was released in 2021 and its price was 4699$. Comparing the average cost of a Gravel e-bike to this one, you will see that Libre EL price is 29.02% more expensive.
Overview of components
Fork material
The fork on this e-bike is made out of carbon, so, it’s a great addition to the e-bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
The Libre EL 2021 e-bike is equipped with aluminum wheels when leaving the factory. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
Nothing is more important on a bike than its ability to brake properly. Kona Libre EL is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Kona Libre EL e-bike has 5 sizes, in the range of 147 cm – 195 cm (4.82 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
A dropper post is included with the Libre EL. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
