Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 100mm -
Fork RockShox Recon Silver TK
-
Groupset Shimano, Alivio -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light 7005 Aluminum Butted
Suspension Fork
Rockshox Recon Silver TK Coil 100mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano XLS Shadow SGS
Front Derailleur
Shimano Alivio
Shift Levers
Shimano Alivio
Cassette
Shimano HG53 11-34 9 spd
Crank
42/34/22
Bottom Bracket
Shimano ES25
Chain
Shimano HG53
Pedals
Wellgo LU-A9
Wheels
Front Hub
Formula DC-20
Rear Hub
Shimano M475 Disc
Rims
Mavic XM119
Spokes
Sandvik Stainless 15g
Tires
Maxxis Aspen 26x2.1
Brakes
Brakes
Avid Elixir 1
Brake Levers
Avid Elixir 1
Disk Rotors
Avid G2 Clean Sweep 180mm
Cockpit
Stem
Kona XC/Road
Handlebar
Kona XC/BC Riser
Grips
Kona Lisa
Headset
FSA
Seat
Saddle
Kona Lisa
Seatpost
Kona Double Clamp w/offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 14" | 16" | 17" | 18" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.47 mm | 1.44 mm | 1.43 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 310 mm | 310 mm |
| Front Center | 625 mm | 650 | 660 mm | 675 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm |
| Stack | 544 mm | 564 mm | 569 mm | 579 mm |
| Reach | 364 mm | 384 mm | 394 mm | 404 mm |
| Top Tube Length | 539 mm | 564 mm | 579 mm | 589 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 360 mm | 405 mm | 430 mm | 455 mm |
| Head Tube Angle | 68 ° | 68 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 100 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 414 mm | 414 mm | 414 mm | 414 mm |
| Wheelbase | 1034 mm | 1064 mm | 1074 mm | 1084 mm |
| Bottom Bracket Drop | 38 mm | 38 mm | 33 mm | 33 mm |
| Standover Height | 724 mm | 744 mm | 764 mm | 779 mm |
| Wheels | 26" | 26" | 26" | 26" |
About this model
Mina belongs to the Kona Mina model. 1 bike variation carries this model name so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Mina components
Fork
This bike has the RockShox Recon Silver TK fork installed. The fork’s travel is 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The Mina 2012 bike is equipped with 26″ aluminum wheels when leaving the factory. These wheels give you great handling over your bike. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
