Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 200mm -
Travel Rear 200mm -
Fork RockShox BoXXer
-
Groupset X9, e*thirteen -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona DH 7005 Aluminum 200mm Travel
Suspension Fork
Rock Shox Boxxer RC 200mm
Rear Shock
Rock Shox Kage RC
Drivetrain
Rear Derailleur
SRAM X9
Front Derailleur
E*Thirteen SS
Shift Levers
SRAM X7 (rh only)
Cassette
SRAM PG1050 11-28t 10 spd
Crank
36t
Bottom Bracket
FSA 83mm
Chain
SRAM PC1051
Pedals
Kona Wah Wah
Wheels
Front Hub
Formula 20mm
Rear Hub
Formula 150x12mm
Rims
Sun MTX33 Sleeved
Spokes
Sandvik Stainless 14g
Tires
Maxxis High Roller 2 DH 26x2.4"
Brakes
Brakes
Avid Code R
Brake Levers
Avid Code R
Disk Rotors
Avid G2CS 200mm
Cockpit
Stem
Kona Jerk
Handlebar
Kona DH
Grips
Kona G-LOG
Headset
FSA Orbit 1.5B ZS No.57B-1
Seat
Saddle
WTB Devo HP Comp
Seatpost
Kona DH
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.462 mm | 1.381 mm | 1.297 mm |
| Bottom Bracket Height | 350 mm | 350 mm | 350 mm |
| Front Center | 720 mm | 755 mm | 795 mm |
| Rake | 45 mm | 45 mm | 45 mm |
| Trail | 117 mm | 117 mm | 122 mm |
| Stack | 570 mm | 580 mm | 590 mm |
| Reach | 390 mm | 420 mm | 455 mm |
| Top Tube Length | 545 mm | 585 mm | 620 mm |
| Seat Tube Angle | 75 ° | 74.7 ° | 74.4 ° |
| Head Tube Angle | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1150 mm | 1185 mm | 1220 mm |
| Bottom Bracket Drop | -15 mm | -15 mm | -15 mm |
| Standover Height | 750 mm | 755 mm | 760 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 152 cm | 157 cm | 175 cm |
| Rider Max Height | 170 cm | 182 cm | 195 cm |
About this model
OPERATOR completes the Kona Operator model. There are 17 bikes that carry this model name.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Downhill bikes
Our math shows that the average cost of a dependable Downhill bike is 3391$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Downhill bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
OPERATOR components
Fork
This bike has the RockShox BoXXer fork installed. The fork’s travel is 200mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
Kona OPERATOR bike has the Rock Shox Kage RC model installed, and has a travel of 200mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
The OPERATOR 2013 bike is equipped with 26″ aluminum wheels when leaving the factory. These wheels give you great handling over your bike. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
OPERATOR comes in 3 sizes, that range from 152 cm – 195 cm (4.99 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
