Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 26" -
Travel Front 200mm -
Travel Rear 200mm -
Fork RockShox BoXXer
-
Groupset X9, X7 -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona DH Carbon w/6061 Aluminum Stays 200mm Travel
Suspension Fork
RockShox Boxxer RC 200mm 20mm DO
Rear Shock
RockShox Kage RC
Drivetrain
Rear Derailleur
SRAM X9 Type 2
Front Derailleur
n/a
Shift Levers
SRAM X7 (rh only)
Cassette
SRAM PG1050 11-28t 10 spd
Crank
36t
Bottom Bracket
Shimano Press Fit 104.5mm
Chain
KMC X10
Chain Guide
The Hive SRS+
Pedals
Kona Wah Wah
Wheels
Front Hub
Formula 20mm
Rear Hub
Formula 157x12mm
Rims
Sun MTX33 Sleeved
Spokes
Sandvik Stainless 14g
Tires
Maxxis High Roller II DH 26x2.4"
Brakes
Brakes
Avid Code R
Brake Levers
Avid Code R
Disk Rotors
Avid G2CS 200mm
Cockpit
Stem
Kona Jerk
Handlebar
Kona DH
Grips
Kona S-LOG
Headset
FSA Orbit 1.5B ZS No.57B-1
Seat
Saddle
WTB Volt Sport SE
Seatpost
Kona DH
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.494 mm | 1.398 mm | 1.348 mm |
| Bottom Bracket Height | 346 mm | 346 mm | 346 mm |
| Front Center | 721 mm | 758 mm | 796 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 121 mm | 121 mm | 121 mm |
| Stack | 581 mm | 590 mm | 608 mm |
| Reach | 389 mm | 422 mm | 451 mm |
| Top Tube Length | 535 mm | 573 mm | 612 mm |
| Seat Tube Angle | 76 ° | 76 ° | 75 ° |
| Seat Tube Length | 417 mm | 417 mm | 417 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 100 mm | 110 mm | 130 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1141 mm | 1178 mm | 1216 mm |
| Bottom Bracket Drop | -3 mm | -3 mm | -3 mm |
| Standover Height | 725 mm | 725 mm | 725 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 152 cm | 157 cm | 175 cm |
| Rider Max Height | 170 cm | 182 cm | 195 cm |
Model Overview
OPERATOR is a Kona Operator model. Kona released 17 bikes variations of this model so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Downhill bikes
If you want an acceptable Downhill bike you should know that the average price is 3391$. However, you could also get a good Downhill bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork
This bike has the RockShox BoXXer fork installed. The fork’s travel is 200mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Kona OPERATOR bike has the RockShox Kage RC model installed, and has a travel of 200mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The wheels on OPERATOR are the 26″ aluminum type. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
For your safety, it is important to have quality breaks on your bike. Kona OPERATOR has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
This bike is available in 3 sizes. They vary from 152 cm – 195 cm (4.99 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
