Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 40mm -
Fork Suntour GVX
-
Groupset microSHIFT Sword -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes TRP Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 6061 Aluminum Butted
Suspension Fork
Suntour GVX32 40mm travel, Tapered, 100x12mm
Rear Shock
n/a
Drivetrain
Rear Derailleur
Microshift Sword Long Cage w/Clutch
Front Derailleur
n/a
Shift Levers
Microshift Sword left dropper/brake and right brake/shifter
Cassette
Microshift Sword 11-48t 10spd
Crank
Microshift Sword, 40t 10sp narrow-wide
Bottom Bracket
Prowheel PF86.5
Chain
KMC X10
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Formula 100x12mm 6-bolt
Rear Hub
Formula 142x12mm 6-bolt, standard road 11sp freehub body
Rims
WTB ST i27 TCS 2.0
Spokes
Stainless Black 14g
Tires
Front: Maxxis Ravager EXO TR 700x50c, Rear: Maxxis Ravager EXO TR 700x50c
Brakes
Brakes
TRP Spyre C
Brake Levers
Microshift Sword
Cockpit
Stem
Kona Gravel 6-degree rise, 48-52: 50mm; 54-58: 60mm
Handlebar
Kona Gravel 20-degree flare, 48: 440mm; 50: 460mm; 52-54: 480mm; 56: 500mm; 58: 520mm
Grips
Kona Cork Tape
Headset
FSA No.57B
Seat
Saddle
WTB Volt
Seatpost
TranzX Dropper +RAD Internal 31.6mm 125mm travel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50cm | 52cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.522 mm | 1.541 mm | 1.565 mm | 1.596 mm | 1.627 mm | 1.682 mm |
| Bottom Bracket Height | 296 mm | 296 mm | 296 mm | 299 mm | 299 mm | 299 mm |
| Front Center | 624 mm | 635 mm | 646 mm | 659 mm | 671 mm | 687 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 81 mm | 81 mm | 82 mm | 80 mm | 81 mm | 82 mm |
| Stack | 566 mm | 581 mm | 598 mm | 616 mm | 636 mm | 666 mm |
| Reach | 372 mm | 377 mm | 382 mm | 386 mm | 391 mm | 396 mm |
| Top Tube Length | 532 mm | 547 mm | 559 mm | 578 mm | 595 mm | 616 mm |
| Seat Tube Angle | 74.2 ° | 73.7 ° | 73.2 ° | 72.7 ° | 72.2 ° | 71.7 ° |
| Seat Tube Length | 410 mm | 410 mm | 455 mm | 455 mm | 500 mm | 535 mm |
| Head Tube Angle | 68.7 ° | 68.7 ° | 68.7 ° | 68.7 ° | 68.7 ° | 68.7 ° |
| Head Tube Length | 116 mm | 132 mm | 148 mm | 172 mm | 193 mm | 225 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1060 mm | 1071 mm | 1082 mm | 1096 mm | 1108 mm | 1124 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 725 mm | 730 mm | 769 mm | 777 mm | 814 mm | 848 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
