Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Ultegra, 105 -
Suspension Rigid -
Drivetrain 3 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 7005 Race Light Aluminum Butted
Suspension Fork
Kona Carbon Race
Drivetrain
Rear Derailleur
Shimano Ultegra GS
Front Derailleur
Shimano 105
Shift Levers
Shimano SL-R770
Cassette
Shimano 105 11-28 10 spd
Crank
52/39/30
Bottom Bracket
FSA MegaExo BB30
Chain
Shimano 105
Pedals
Shimano A530
Wheels
Front Hub
Mavic Aksium Wheelset
Rear Hub
Mavic Aksium Wheelset
Rims
Mavic Aksium Wheelset
Spokes
Mavic Aksium Wheelset
Tires
Continental UltraSport 700x23C Kevlar
Brakes
Brakes
Tektro R538
Brake Levers
Shimano BL-R550
Cockpit
Stem
FSA OS150
Handlebar
FSA XC-180 OS
Grips
Kona Race Light
Headset
FSA No. 11 AGY
Seat
Saddle
WTB Valcon Comp
Seatpost
FSA SL-280 w/offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 53cm | 56cm | 59cm | 61cm |
|---|---|---|---|---|---|
| Bottom Bracket Height | 274 mm | 277 mm | 277 mm | 280 mm | 280 mm |
| Front Center | 600 mm | 604 mm | 620 mm | 626 mm | 647 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Top Tube Length | 541 mm | 556 mm | 571 mm | 591 mm | 611 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 440 mm | 480 mm | 510 mm | 540 mm | 560 mm |
| Head Tube Angle | 70 ° | 71 ° | 71 ° | 72 ° | 72 ° |
| Head Tube Length | 115 mm | 135 mm | 165 mm | 185 mm | 200 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1038 mm | 1042 mm | 1058 mm | 1065 mm | 1086 mm |
| Standover Height | 717 mm | 748 mm | 778 mm | 803 mm | 818 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
PHD is part of the Kona Phd model. 2 bikes variations carry this model name so far.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Commuter bikes average price
According to our calculations, the average cost of a Commuter bike that is reliable is 762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Commuter bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
As for the wheels, Kona PHD 2011, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Kona PHD has Rim brakes installed. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
