Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 134mm -
Fork RockShox Recon Silver RL
-
Groupset Deore, Race Face -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
147cm - 154cm
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 6061 Aluminum Butted 134mm Travel
Suspension Fork
RockShox Recon RL Solo Air 140mm Tapered
Rear Shock
RockShox Monarch R Solo Air
Drivetrain
Rear Derailleur
Shimano Deore Shadow Plus
Front Derailleur
n/a
Shift Levers
Shimano Deore
Cassette
Shimano HG500 11-42t 10spd
Crank
RaceFace Ride, 30t NW
Bottom Bracket
Shimano PF92
Chain
KMC X10
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Shimano Deore 100x15mm (centerlock)
Rear Hub
Shimano Deore 142x12mm (centerlock)
Rims
WTB SX25
Spokes
Stainless Black 14g
Tires
Maxxis Minion DHF EXO TR DUAL 27.5x2.3"
Brakes
Brakes
Shimano Hydraulic
Brake Levers
Shimano Hydraulic
Disk Rotors
Shimano RT10 180mm (centerlock)
Cockpit
Stem
Kona XC/BC 35
Handlebar
Kona XC/BC 35
Grips
Kona Key Grip
Headset
FSA No.57B
Seat
Saddle
Kona OB
Seatpost
Trans-X Dropper Internal 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.39 mm | 1.33 mm | 1.27 mm | 1.2 mm |
| Bottom Bracket Height | 343 mm | 343 mm | 343 mm | 343 mm | 343 mm |
| Front Center | 674 mm | 717 mm | 746 mm | 772 mm | 811 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 106 mm | 105 mm | 105 mm | 105 mm | 105 mm |
| Stack | 578 mm | 596 mm | 605 mm | 610 mm | 619 mm |
| Reach | 395 mm | 430 mm | 455 mm | 480 mm | 515 mm |
| Top Tube Length | 552 mm | 594 mm | 623 mm | 650 | 688 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 405 mm | 405 mm | 410 mm | 460 mm | 485 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 95 mm | 115 mm | 125 mm | 130 mm | 140 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1104 mm | 1147 mm | 1176 mm | 1203 mm | 1242 mm |
| Bottom Bracket Drop | 12 mm | 12 mm | 12 mm | 12 mm | 12 mm |
| Standover Height | 705 mm | 705 mm | 710 mm | 710 mm | 710 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 147 cm | 152 cm | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 154 cm | 170 cm | 182 cm | 195 cm | 195 cm |
Model Overview
Process 134 SE completes the Kona Process 134 model. Kona released 38 bikes variations of this model so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2019 for 2199$. Comparing the average cost of a Trail bike to this one, you will see that Process 134 SE price is 25.6% smaller.
Process 134 SE components
Fork
The fork installed on this bike is the RockShox Recon Silver RL model. The travel on this model is 140mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
As for the rear shock, this bike has the RockShox Monarch R Solo Air model, with a travel of 134mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
When it comes to wheels, the Process 134 SE bike is equipped with the 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Process 134 SE comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 147 cm – 195 cm (4.82 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
The Kona model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
