Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 160mm -
Travel Rear 150mm -
Fork RockShox Lyrik
-
Groupset X9, X7 -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 6069 Aluminum Butted 150mm Travel
Suspension Fork
RockShox Lyrik R Coil 160mm
Rear Shock
RockShox Monarch R HV
Drivetrain
Rear Derailleur
SRAM X9 Type 2
Front Derailleur
SRAM X7 Direct Mount
Shift Levers
SRAM X7
Cassette
SRAM PG1030 11-36t 10 spd
Crank
24/38t
Bottom Bracket
SRAM Press Fit GXP
Chain
SRAM PC1031
Pedals
Kona Wah Wah
Wheels
Front Hub
Formula 20mm
Rear Hub
Formula 142x12mm
Rims
WTB ST i23 TCS
Spokes
Stainless 14g
Tires
Maxxis High Roller 2 26x2.4"
Brakes
Brakes
Avid Elixir 5
Brake Levers
Avid Elixir 5
Disk Rotors
Avid G2 Clean Sweep 180mm
Cockpit
Stem
Kona XC/BC
Handlebar
Kona XC/BC Riser
Grips
Kona G-LOG
Headset
FSA Orbit 1.5 ZS No.57
Seat
Saddle
WTB Volt Comp
Seatpost
Krank Brothers Kronolog
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.432 mm | 1.388 mm | 1.333 mm | 1.271 mm |
| Bottom Bracket Height | 350 mm | 350 mm | 350 mm | 350 mm |
| Front Center | 710 mm | 735 mm | 765 mm | 795 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm |
| Trail | 112 mm | 112 mm | 111 mm | 115 mm |
| Stack | 580 mm | 590 mm | 600 mm | 610 mm |
| Reach | 405 mm | 425 mm | 450 mm | 480 mm |
| Top Tube Length | 575 mm | 600 mm | 630 mm | 660 mm |
| Seat Tube Angle | 73.5 ° | 73.4 ° | 73.4 ° | 73.3 ° |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 120 mm | 130 mm | 140 mm | 150 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1135 mm | 1160 mm | 1190 mm | 1220 mm |
| Bottom Bracket Drop | -15 mm | -15 mm | -15 mm | -15 mm |
| Standover Height | 775 mm | 790 mm | 810 mm | 835 mm |
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 152 cm | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 182 cm | 195 cm | 195 cm |
Model Overview
PROCESS is a Kona Process model. There is 1 bike that carries this model name.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Enduro bikes
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
PROCESS components
Fork
This bike has the RockShox Lyrik fork installed. The fork’s travel is 160mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
Kona PROCESS bike has the RockShox Monarch R HV model installed, and has a travel of 150mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
As for the wheels, Kona PROCESS 2013, has a 26″ aluminum model. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
For your safety, it is important to have quality breaks on your bike. Kona PROCESS has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 152 cm – 195 cm (4.99 ft – 6.4 ft). In short, you can easily find one that suits you.
