Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b -
Travel Front 120mm -
Fork RockShox Recon Silver RL
-
Groupset NX, FSA -
Suspension Hardtail -
Motor Bosch 250W 75Nm mid-drive -
Battery Bosch 500W -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 7005 Aluminum Butted
Suspension Fork
RockShox Recon Silver RL Solo Air 120mm Tapered 110 Spacing
Rear Shock
n/a
Drivetrain
Rear Derailleur
SRAM NX
Front Derailleur
n/a
Shift Levers
SRAM NX
Cassette
SRAM PG1130 11-42t 11spd
Crank
FSA E-Bike, 14t
Bottom Bracket
n/a
Chain
SRAM PC1110
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Formula 110x15mm
Rear Hub
Formula 148x12mm
Rims
WTB Scraper i40 Pinned TCS
Spokes
Stainless Black 14g
Tires
Maxxis Chronicle 27.5x3.0"
Brakes
Brakes
SRAM Level T
Brake Levers
SRAM Level T
Disk Rotors
SRAM Centerline 180mm
Cockpit
Stem
Kona XC/BC 35
Handlebar
Kona XC/BC 35
Grips
Kona Key Grip
Headset
FSA No.57B
Seat
Saddle
WTB Volt Sport
Seatpost
Kona Thumb 31.6mm
Motor & Battery
Motor
Bosch Performance Line CX 20MPH
Battery
Bosch 500W
Remote
Bosch Purion
Charger
2A Compact charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.43 mm | 1.38 mm |
| Bottom Bracket Height | 298 mm | 298 mm | 298 mm |
| Front Center | 698 mm | 727 mm | 755 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 73 mm | 72 mm | 73 mm |
| Stack | 630 mm | 639 mm | 649 mm |
| Reach | 422 mm | 447 mm | 472 mm |
| Top Tube Length | 622 mm | 650 | 678 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 405 mm | 455 mm | 505 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm |
| Chainstay Length | 495 mm | 495 mm | 495 mm |
| Wheelbase | 1186 mm | 1215 mm | 1243 mm |
| Bottom Bracket Drop | 64 mm | 64 mm | 64 mm |
| Standover Height | 750 mm | 785 mm | 819 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Remote completes the Kona E Remote model. 16 e-bikes variations carry this model name so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Utility e-bikes average price
If you want to purchase a solid Utility e-bike, it is important to know that the average cost is 3636$. However, this doesn’t mean that if you spend less money on an Utility e-bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2018 for 4099$. Comparing this to the average Utility e-bike price, we see that the price is 12.73% more expensive.
Overview of components
Fork
The fork installed on this bike is the RockShox Recon Silver RL model. The travel on this model is 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The wheels on Remote are the aluminum type. After 700c wheels, 650b is the second most popular choice for road bikes. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, you can easily find one that suits you.
