Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NCX
-
Groupset Alivio, FSA -
Suspension Hardtail -
Motor Bosch 250W 63Nm mid-drive -
Battery Bosch 500W -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 6061 Aluminum Butted
Suspension Fork
Suntour NCX D LO Coil Spring 63mm
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Alivio
Front Derailleur
n/a
Shift Levers
Shimano Alivio
Cassette
Shimano Acera 11-34t 9spd
Crank
FSA Metropolis E-Bike, 15t
Bottom Bracket
n/a
Chain
KMC X9
Chain Guide
Guard
Pedals
Kona JS2
Wheels
Front Hub
Formula 100x9mm
Rear Hub
Joytech 135x10mm
Rims
WTB SX19
Spokes
Stainless Black 14g
Tires
Schwalbe Marathon Mondial HS 428 700x40c
Brakes
Brakes
Shimano Acera
Brake Levers
Shimano Acera
Disk Rotors
Shimano 160mm
Cockpit
Stem
Kona Control
Handlebar
Kona Aluminum Riser
Grips
Kona Control
Headset
FSA No.10P
Seat
Saddle
WTB Pure Sport
Seatpost
Kona Thumb w/Offset 27.2mm
Motor & Battery
Motor
Bosch Performance Line 20MPH/25KPH EU
Battery
Bosch 500W
Remote
Bosch Intuvia
Charger
2A Compact charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.47 mm | 1.45 mm | 1.42 mm |
| Bottom Bracket Height | 295 mm | 295 mm | 295 mm | 295 mm |
| Front Center | 633 mm | 661 mm | 688 mm | 714 mm |
| Rake | 38 mm | 38 mm | 38 mm | 38 mm |
| Trail | 87 mm | 88 mm | 87 mm | 87 mm |
| Stack | 591 mm | 610 mm | 629 mm | 647 mm |
| Reach | 393 mm | 415 mm | 435 mm | 455 mm |
| Top Tube Length | 569 mm | 596 mm | 622 mm | 647 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 110 mm | 130 mm | 150 mm | 170 mm |
| Chainstay Length | 478 mm | 478 mm | 478 mm | 478 mm |
| Wheelbase | 1104 mm | 1132 mm | 1160 mm | 1186 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 693 mm | 733 mm | 773 mm | 808 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Splice-E is a Kona E Splice E model. Kona launched 4 e-bikes of this model so far.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Hybrid e-bikes average price
If you want an acceptable Hybrid e-bike you should know that the average price is 2480$. However, even though the average price of a Hybrid e-bike is lower, you might still be able to get a top-quality e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2018 for 3499$. In conclusion, this e-bike price is 41.09% higher than the price of the average Hybrid e-bike.
Splice-E components
Fork
The Splice-E comes factory-installed with the SunTour NCX fork. This has a travel range of 63mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The wheels on Splice-E are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
This e-bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
