Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NCX
-
Groupset Alivio, FSA -
Suspension Hardtail -
Motor Bosch 250W 50Nm mid-drive -
Battery Bosch PowerPack 400Wh -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 6061 Aluminum Butted
Suspension Fork
Suntour NCX D LO Coil Spring 63mm Tapered 100 Spacing
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Alivio
Front Derailleur
n/a
Shift Levers
Shimano Alivio
Cassette
Shimano Alivio 11-34t 9spd
Crank
FSA E-Bike, 38t
Bottom Bracket
n/a
Chain
KMC X9
Chain Guide
FSA E-Bike Chain Guard
Pedals
Kona JS2
Wheels
Front Hub
Formula 100x15mm
Rear Hub
Formula 135x10mm
Rims
WTB SX19
Spokes
Stainless Black 14g
Tires
WTB Venture Comp 700x40c
Brakes
Brakes
Shimano Hydraulic
Brake Levers
Shimano Hydraulic
Disk Rotors
Shimano 160mm
Cockpit
Stem
Kona Control
Handlebar
Kona Aluminum Riser
Grips
Kona Key Grip
Headset
FSA No.57B
Seat
Saddle
WTB Pure Sport
Seatpost
Kona Thumb w/Offset 31.6mm
Motor & Battery
Motor
Bosch Active Line Plus 20MPH
Battery
Bosch PowerPack 400Wh
Remote
Bosch Intuvia
Charger
2A Compact Charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.45 mm | 1.43 mm | 1.4 mm |
| Bottom Bracket Height | 295 mm | 295 mm | 295 mm | 295 mm |
| Front Center | 633 mm | 667 mm | 694 mm | 720 mm |
| Rake | 38 mm | 38 mm | 38 mm | 38 mm |
| Trail | 91 mm | 88 mm | 87 mm | 87 mm |
| Stack | 591 mm | 610 mm | 629 mm | 647 mm |
| Reach | 399 mm | 421 mm | 441 mm | 461 mm |
| Top Tube Length | 569 mm | 596 mm | 622 mm | 647 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 110 mm | 130 mm | 150 mm | 170 mm |
| Chainstay Length | 478 mm | 478 mm | 478 mm | 478 mm |
| Wheelbase | 1105 mm | 1138 mm | 1166 mm | 1192 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 705 mm | 737 mm | 777 mm | 817 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Splice-E completes the Kona E Splice E model. Kona released 4 e-bikes variations of this model so far.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Hybrid e-bikes
According to our calculations, the average cost of a Hybrid e-bike that is reliable is 2480$. However, you could also get a good Hybrid e-bike even if you pay a lower amount than the average price. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
When Kona released this model in 2020, its price was 2999$. In conclusion, this e-bike price is 20.93% more expensive than the price of the average Hybrid e-bike.
Splice-E components
Fork
Kona Splice-E 2020 e-bike is equipped with the SunTour NCX fork, and has 63mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
As for the wheels, Kona Splice-E 2020, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Kona Splice-E has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Splice-E comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
