Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 26" -
Travel Front 130mm -
Fork RockShox
-
Groupset Deore, e*thirteen -
Suspension Hardtail -
Drivetrain 1 × 9 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Cromoly Butted
Suspension Fork
RockShox Tora 289 U-Turn 85-130mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Deore SGS
Front Derailleur
E*13 LS1
Shift Levers
Shimano Alivio
Cassette
Shimano HG61 12-36 9 spd
Crank
34T
Bottom Bracket
FSA ISIS
Chain
Shimano HG53
Pedals
Kona JackShit
Wheels
Front Hub
Formula Disc
Rear Hub
Shimano M475 Disc
Rims
WTB FX 23
Spokes
Sandvik Stainless 14g
Tires
Maxxis Ardent 26x2.4
Brakes
Brakes
Avid Elixir 1
Brake Levers
Avid Elixir 1
Disk Rotors
Avid G2 180mm
Cockpit
Stem
Kona XC/BC
Handlebar
Kona XC/BC Riser
Grips
Kona G-LOG
Headset
FSA
Seat
Saddle
WTB Volt Comp
Seatpost
Kona Double Clamp
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 14" | 16" | 18" | 20" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.57 mm | 1.53 mm | 1.46 mm | 1.42 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 305 mm | 305 mm |
| Front Center | 650 | 680 mm | 705 mm | 730 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm |
| Stack | 591 mm | 606 mm | 616 mm | 626 mm |
| Reach | 376 mm | 396 mm | 421 mm | 441 mm |
| Top Tube Length | 566 mm | 591 mm | 616 mm | 641 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 355 mm | 405 mm | 455 mm | 510 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1076 mm | 1106 mm | 1131 mm | 1156 mm |
| Bottom Bracket Drop | 38 mm | 38 mm | 38 mm | 38 mm |
| Standover Height | 746 mm | 776 mm | 806 mm | 836 mm |
| Wheels | 26" | 26" | 26" | 26" |
Model Overview
Steely completes the Kona Steely model. 2 bikes variations carry this model name so far.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork
The RockShox is included from the factory. It has a travel distance of 130mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The wheels on Steely are the 26″ aluminum type. These wheels give you great handling over your bike. However, they provide less traction than 29″ wheels do.
Brakes
When you want to stop the bike in time, the brakes are vital. The Steely has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
