Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 24" -
Travel Front 100mm -
Travel Rear 100mm -
Fork RockShox 30 Silver TK
-
Groupset Deore, Altus -
Suspension Full -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 7005 DH Aluminum
Suspension Fork
RockShox XC 30 Silver Solo Air 100mm Tapered
Rear Shock
Fastrax Air
Drivetrain
Rear Derailleur
Shimano Deore
Front Derailleur
n/a
Shift Levers
Shimano Altus
Cassette
Shimano Alivio 11-34t 9spd
Crank
36t/Guard
Bottom Bracket
FSA
Chain
KMC Z99
Chain Guide
E13 FreeChucker
Pedals
Wellgo Platform
Wheels
Front Hub
Shimano
Rear Hub
Shimano
Rims
Alex DM24
Spokes
Stainless Black 14g
Tires
Maxxis High Roller 24x2.5"
Brakes
Brakes
Shimano Hydrualic
Brake Levers
Shimano Hydrualic
Disk Rotors
Shimano Altus 180mm Centerlock
Cockpit
Stem
Kona Jerk
Handlebar
Kona OB
Grips
Kona S-LOG
Headset
FSA Orbit 1.5 ZS No.57B
Seat
Saddle
Kona DJ
Seatpost
Kona Thumb OB 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM |
|---|---|
| Stack Reach Ratio | 1.53 mm |
| Bottom Bracket Height | 324 mm |
| Front Center | 618 mm |
| Rake | 40 mm |
| Stack | 528 mm |
| Reach | 346 mm |
| Top Tube Length | 503 mm |
| Seat Tube Angle | 73.5 ° |
| Seat Tube Length | 330 mm |
| Head Tube Angle | 67 ° |
| Head Tube Length | 115 mm |
| Chainstay Length | 412 mm |
| Wheelbase | 1030 mm |
| Bottom Bracket Drop | 4 mm |
| Standover Height | 693 mm |
| Wheels | 24" |
Model Overview
Stinky 24 is part of the Kona Stinky model. Kona launched 14 bikes of this model so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Youth bikes
If you want an acceptable Youth bike you should know that the average price is 278$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Youth bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Kona released this model in 2017, its price was 1799$. Doing a quick comparison, we notice that Stinky 24 price is 547.12% more expensive than the average cost of a Youth bike.
Overview of components
Fork
Kona Stinky 24 2017 bike is equipped with the RockShox 30 Silver TK fork, and has 100mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
From the factory, it comes with the Fastrax Air rear shock model, which has a travel of 100mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
The Stinky 24 2017 bike is equipped with 24″ aluminum wheels when leaving the factory. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
For your safety, it is important to have quality breaks on your bike. Kona Stinky 24 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
