Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 100mm -
Fork Marzocchi
-
Groupset Deore, e*thirteen -
Suspension Hardtail -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Clump 7005 Aluminum
Suspension Fork
Marzocchi DJ3 100mm w/20mm TA
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Deore GS
Front Derailleur
E*13 LS1
Shift Levers
Shimano Alivio
Cassette
Shimano HG20 11-34 9 spd
Crank
34T
Bottom Bracket
RPM ISIS DH
Chain
Shimano HG50
Pedals
Kona Jackshit
Wheels
Front Hub
Formula Disc
Rear Hub
Shimano M475 Disc
Rims
Alex DM-24
Spokes
Stainless 14g
Tires
Maxxis DTH 26x2.35
Brakes
Brakes
Shimano M446 Hydraulic Disc
Brake Levers
Shimano M446 Hydraulic Disc
Disk Rotors
Shimano 180mm
Cockpit
Stem
Kona OB/DH
Handlebar
Kona OB/DH Riser
Grips
Kona G-LOG
Headset
FSA
Seat
Saddle
Kona DJ
Seatpost
Kona Pivotal
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 13" | 15" | 17" |
|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.45 mm | 1.36 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm |
| Front Center | 620 mm | 660 mm | 695 mm |
| Rake | 50 mm | 50 mm | 50 mm |
| Stack | 558 mm | 568 mm | 583 mm |
| Reach | 363 mm | 393 mm | 428 mm |
| Top Tube Length | 543 mm | 583 mm | 618 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 330 mm | 380 mm | 430 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 110 mm | 120 mm | 140 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1043 mm | 1078 mm | 1118 mm |
| Bottom Bracket Drop | 33 mm | 33 mm | 33 mm |
| Standover Height | 718 mm | 743 mm | 773 mm |
| Wheels | 26" | 26" | 26" |
About this model
Stuff belongs to the Kona Stuff model. 3 bikes variations carry this model name so far.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork
The Marzocchi is included from the factory. It has a travel distance of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
When leaving the production line, the Stuff model has 26″ aluminum wheels. These wheels give you great handling over your bike. However, they provide less traction than 29″ wheels do.
Brakes
Nothing is more important on a bike than its ability to brake properly. Kona Stuff is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
