Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 200mm -
Travel Rear 200mm -
Fork RockShox BoXXer
-
Groupset Saint, e*thirteen LG1 Plus -
Suspension Full -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
157cm - 182cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona DH 7005 Aluminum 200mm Travel
Suspension Fork
RockShox Boxxer WC 200mm w/20mm TA
Rear Shock
Fox DHX RC4
Drivetrain
Rear Derailleur
Shimano Saint
Front Derailleur
E*13 LG1+
Shift Levers
Shimano Saint
Cassette
Shimano LX 11-28 9 spd
Crank
Shimano Saint 36T
Bottom Bracket
Shimano Saint
Chain
Shimano Deore XT
Pedals
Kona Wah Wah
Wheels
Front Hub
Shimano Saint
Rear Hub
Shimano Saint
Rims
Mavic EX 729
Spokes
Sandvik Stainless 14g
Tires
Maxxis Minion DHF 26x2.5
Brakes
Brakes
Shimano Saint
Brake Levers
Shimano Saint
Disk Rotors
Shimano Saint 203mm
Cockpit
Stem
Easton Havoc
Handlebar
Easton Havoc
Grips
Kona G-LOG
Headset
Orbit 1.5 ZS NO.57-1
Seat
Saddle
WTB Devo Team
Seatpost
Easton Havoc
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | Short | MD | Long |
|---|---|---|---|
| Bottom Bracket Height | 350 mm | 350 mm | 350 mm |
| Front Center | 722 mm | 758 mm | 795 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Top Tube Length | 546 mm | 584 mm | 622 mm |
| Seat Tube Angle | 75 ° | 74.7 ° | 74.4 ° |
| Head Tube Angle | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 439 mm | 439 mm | 439 mm |
| Wheelbase | 1160 mm | 1197 mm | 1233 mm |
| Bottom Bracket Drop | -7 mm | -7 mm | -7 mm |
| Standover Height | 749 mm | 755 mm | 761 mm |
| Wheels | 26" | 26" | 26" |
About this model
SUPREME OPERATOR is a Kona Supreme model. There are 7 bikes that carry this model name.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Downhill bikes
If you want to purchase a solid Downhill bike, it is important to know that the average cost is 3391$. However, even though the average price of a Downhill bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
SUPREME OPERATOR components
Fork
Kona SUPREME OPERATOR 2011 bike is equipped with the RockShox BoXXer fork, and has 200mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The SUPREME OPERATOR has a rear shock with a travel of 200mm. The model Fox DHX RC4 is the one installed in this bike. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
The wheels on SUPREME OPERATOR are the 26″ aluminum type. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The SUPREME OPERATOR has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
