Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 26" -
Travel Front 200mm -
Travel Rear 200mm -
Fork RockShox BoXXer
-
Groupset X01 -
Suspension Full -
Drivetrain 1 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona DH Carbon w/6061 Aluminum Stays 200mm Travel
Suspension Fork
RockShox Boxxer WC 200mm 20mm DO
Rear Shock
RockShox Vivid Coil
Drivetrain
Rear Derailleur
SRAM DH XO1
Shift Levers
SRAM DH XO1
Cassette
SRAM XG795 10-24 7spd
Crank
32t
Bottom Bracket
SRAM Press Fit GXP 104.5mm
Chain
SRAM XX1
Chain Guide
The Hive SRS+32
Pedals
n/a
Wheels
Front Hub
Hope Pro II 20mm
Rear Hub
Hope Pro II 157x12mm
Rims
Mavic EX729
Spokes
Sandvik Stainless 14g Black
Tires
Maxxis DHF DH 3C 26x2.5"
Brakes
Brakes
Avid XO Trail
Brake Levers
Avid XO Trail
Disk Rotors
Avid Centerline 200mm Ti
Cockpit
Stem
Truvativ Holzfeller
Handlebar
Truvativ BooBar
Grips
Kona S-LOG
Headset
FSA Orbit C-40 No.42
Seat
Saddle
WTB Devo Team
Seatpost
Truvativ Noir
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.494 mm | 1.398 mm | 1.348 mm |
| Bottom Bracket Height | 347 mm | 347 mm | 347 mm |
| Front Center | 721 mm | 758 mm | 796 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 121 mm | 121 mm | 121 mm |
| Stack | 581 mm | 590 mm | 608 mm |
| Reach | 389 mm | 422 mm | 451 mm |
| Top Tube Length | 535 mm | 573 mm | 612 mm |
| Seat Tube Angle | 76 ° | 76 ° | 75 ° |
| Seat Tube Length | 417 mm | 417 mm | 417 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 100 mm | 110 mm | 130 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1141 mm | 1178 mm | 1216 mm |
| Bottom Bracket Drop | -4 mm | -4 mm | -4 mm |
| Standover Height | 725 mm | 725 mm | 725 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 152 cm | 157 cm | 175 cm |
| Rider Max Height | 170 cm | 182 cm | 195 cm |
Model Overview
SUPREME OPERATOR belongs to the Kona Supreme model. Kona released 7 bikes variations of this model so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Downhill bikes
If you want an acceptable Downhill bike you should know that the average price is 3391$. However, even if your budget is less than the average, you might still be able to get a top-quality Downhill bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
SUPREME OPERATOR components
Fork
The RockShox BoXXer is included from the factory. It has a travel distance of 200mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The shock that’s installed on this bike is RockShox Vivid Coil, with a travel distance of 200mm. Rear shocks improve riding comfort and give you greater control over all terrains. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
When leaving the production line, the SUPREME OPERATOR model has 26″ aluminum wheels. Being a little smaller, these wheels will fit both small and tall riders. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Kona SUPREME OPERATOR is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
SUPREME OPERATOR comes in 3 sizes, that range from 152 cm – 195 cm (4.99 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
