Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset XT, Tiagra -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
56cm
175cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Cromoly Butted
Suspension Fork
Kona Project Two Touring
Drivetrain
Rear Derailleur
Shimano XT Shadow SGS
Front Derailleur
Shimano Tiagra
Shift Levers
Shimano Bar Con
Cassette
Shimano HG-50 11-32 9 spd
Crank
50/39/30
Bottom Bracket
Shimano Sora
Chain
Shimano HG50
Pedals
N/A
Wheels
Front Hub
Shimano Deore Disc
Rear Hub
Shimano Deore Disc
Rims
Freedom Ryder 21
Spokes
Sandvik Stainless 14g
Tires
Continental Contact 700x32C
Brakes
Brakes
Avid BB7 Road
Brake Levers
Tektro RL-340
Disk Rotors
Avid G2 Clean Sweep 160mm
Cockpit
Stem
Kona Deluxe Road Stem
Handlebar
Kona Deluxe Road Bar
Grips
Kona Cork Tape w/gel
Headset
FSA
Seat
Saddle
WTB Rocket V Comp
Seatpost
Kona Double Clamp w/offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 53cm | 56cm | 59cm | 61cm |
|---|---|---|---|---|---|
| Bottom Bracket Height | 277 mm | 277 mm | 282 mm | 282 mm | 282 mm |
| Front Center | 598 mm | 609 mm | 616 mm | 631 mm | 641 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Top Tube Length | 541 mm | 556 mm | 571 mm | 591 mm | 611 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 440 mm | 480 mm | 510 mm | 540 mm | 560 mm |
| Head Tube Angle | 71 ° | 71 ° | 71.5 ° | 71.5 ° | 72 ° |
| Head Tube Length | 115 mm | 140 mm | 160 mm | 180 mm | 195 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1035 mm | 1046 mm | 1054 mm | 1069 mm | 1079 mm |
| Bottom Bracket Drop | 59 mm | 59 mm | 54 mm | 54 mm | 54 mm |
| Standover Height | 734 mm | 764 mm | 791 mm | 814 mm | 830 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
SUTRA is part of the Kona Sutra model. 26 bikes variations carry this model name so far.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Touring bikes average price
If you want to purchase a solid Touring bike, it is important to know that the average cost is 1007$. However, even though the average price of a Touring bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
SUTRA components
Fork material
The fork is made out of steel, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels size
The SUTRA 2011 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Kona SUTRA is equipped with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
