Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset XT, Tiagra -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Cromoly Butted
Suspension Fork
Kona Project Two Touring
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano XT Shadow SGS
Front Derailleur
Shimano Tiagra
Shift Levers
Shimano Bar Con
Cassette
Shimano HG50 11-32 9 spd
Crank
50/39/30
Bottom Bracket
Shimano Sora
Chain
Shimano HG50
Pedals
N/A
Wheels
Front Hub
Shimano Deore Disc
Rear Hub
Shimano Deore Disc
Rims
Freedom Ryder 21
Spokes
Sandvik Stainless 14g
Tires
Continental Contact 700x32C
Brakes
Brakes
Avid BB7 Road
Brake Levers
Tektro RL-340
Disk Rotors
Avid G2 Clean Sweep 160mm
Cockpit
Stem
Kona Deluxe Road Stem
Handlebar
Kona Deluxe Road Bar
Grips
Kona Cork Tape w/gel
Headset
TH 848
Seat
Saddle
WTB Rocket V Comp
Seatpost
Kona Double Clamp w/offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | C49cm | C53cm | C56cm | C59cm | C61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.45 mm | 1.48 mm | 1.49 mm | 1.49 mm |
| Bottom Bracket Height | 277 mm | 277 mm | 282 mm | 282 mm | 282 mm |
| Front Center | 598 mm | 609 mm | 616 mm | 631 mm | 641 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Stack | 546 mm | 570 mm | 586 mm | 605 mm | 621 mm |
| Reach | 388 mm | 392 mm | 397 mm | 406 mm | 416 mm |
| Top Tube Length | 540 mm | 555 mm | 570 mm | 590 mm | 610 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 490 mm | 530 mm | 560 mm | 590 mm | 610 mm |
| Head Tube Angle | 71 ° | 71 ° | 71.5 ° | 71.5 ° | 72 ° |
| Head Tube Length | 115 mm | 140 mm | 160 mm | 180 mm | 195 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1034 mm | 1045 mm | 1053 mm | 1068 mm | 1078 mm |
| Bottom Bracket Drop | 59 mm | 59 mm | 54 mm | 54 mm | 54 mm |
| Standover Height | 733 mm | 763 mm | 790 mm | 813 mm | 829 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Sutra completes the Kona Sutra model. There are 26 bikes that carry this model name.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Touring bikes
According to our math, the average price for a trustworthy Touring bike is 1007$. However, this doesn’t mean that if you spend less money on a Touring bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Overview of components
Fork material
Sutra has a steel fork, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels
As for the wheels, Kona Sutra 2012, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Kona Sutra has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, performance-wise there is room for improvement.
