Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Shimano, Deore -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
56cm
175cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Cromoly
Suspension Fork
Kona Project Two Touring
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano LX Treking
Front Derailleur
Shimano Deore
Shift Levers
Shimano BarCon
Cassette
Shimano Deore 11-32t 9 spd
Crank
26/36/48t
Bottom Bracket
Shimano BB51
Chain
KMC HG53
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Shimano Deore
Rear Hub
Shimano Deore
Rims
Freedom Ryder 21
Spokes
Sandvik Stainless 14g
Tires
Continental Contact 700x32C
Brakes
Brakes
Hayes CX Expert
Brake Levers
Tektro RL340
Disk Rotors
Hayes L Series 160mm
Cockpit
Stem
Kona XC/Road
Handlebar
Kona Deluxe Road Bar
Grips
Kona Cork Tape
Headset
TH 848
Seat
Saddle
WTB Rocket V Comp
Seatpost
Kona Double Clamp w/Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 49cm | 53cm | 56cm | 59cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.45 mm | 1.51 mm | 1.55 mm | 1.55 mm | 1.54 mm |
| Bottom Bracket Height | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm |
| Front Center | 592 mm | 598 mm | 604 mm | 609 mm | 624 mm | 633 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 87 mm | 73 mm | 70 mm | 66 mm | 64 mm | 60 mm |
| Stack | 529 mm | 550 mm | 576 mm | 596 mm | 617 mm | 629 mm |
| Reach | 387 mm | 380 mm | 382 mm | 385 mm | 399 mm | 409 mm |
| Top Tube Length | 522 mm | 537 mm | 552 mm | 567 mm | 587 mm | 607 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 470 mm | 490 mm | 530 mm | 560 mm | 590 mm | 610 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72.5 ° |
| Head Tube Length | 100 mm | 120 mm | 145 mm | 165 mm | 185 mm | 195 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1020 mm | 1027 mm | 1033 mm | 1038 mm | 1053 mm | 1062 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 752 mm | 772 mm | 803 mm | 827 mm | 852 mm | 868 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
SUTRA is part of the Kona Sutra model. There are 26 bikes that carry this model name.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Touring bikes
If you want an acceptable Touring bike you should know that the average price is 1007$. However, this doesn’t mean that if you spend less money on a Touring bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
SUTRA components
Fork material
The fork on this bike is made out of steel, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels size
The wheels on SUTRA are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Kona SUTRA has Mechanical Disc brakes installed. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
