Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Wheels 29" -
Suspension Rigid -
Drivetrain Single Speed -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Cromoly Butted
Suspension Fork
P2 29er
Drivetrain
Rear Derailleur
N/A
Front Derailleur
N/A
Shift Levers
N/A
Cassette
Formula 18T
Crank
32T/Guard
Bottom Bracket
FSA MegaExo
Chain
KMC Z610
Pedals
Kona Jackshit
Wheels
Front Hub
Formula Disc
Rear Hub
Formula Disc
Rims
Alex EN-24
Spokes
Sandvik Stainless 15g fr / 14g rr
Tires
Maxxis Ignitor 29x2.1
Brakes
Brakes
Avid BB-7 MTB Disc
Brake Levers
Avid FR-5
Disk Rotors
Avid G2 Clean Sweep 185mm
Cockpit
Stem
Kona XC/Road
Handlebar
Kona Energy
Grips
Kona Race Light LOG
Headset
FSA
Seat
Saddle
WTB Valcon Comp
Seatpost
Kona Double Clamp w/offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 40.6cm | 45.7cm | 48.3cm | 50.8cm | 55.9cm |
|---|---|---|---|---|---|
| Bottom Bracket Height | 305 mm | 310 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 659 mm | 672 mm | 674 mm | 676 mm | 694 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Top Tube Length | 578 mm | 603 mm | 616 mm | 628 mm | 654 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 406 mm | 457 mm | 483 mm | 508 mm | 559 mm |
| Head Tube Angle | 68.5 ° | 70 ° | 70 ° | 71 ° | 72 ° |
| Head Tube Length | 100 mm | 120 mm | 130 mm | 140 mm | 160 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1093 mm | 1112 mm | 1109 mm | 1111 mm | 1129 mm |
| Bottom Bracket Drop | 69 mm | 64 mm | 64 mm | 64 mm | 64 mm |
| Standover Height | 771 mm | 802 mm | 818 mm | 836 mm | 871 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
About this model
UNIT is part of the Kona Unit model. Kona launched 20 bikes of this model so far.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
UNIT components
Wheels size
When it comes to wheels, the UNIT bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The UNIT comes with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
