Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Suspension Rigid -
Drivetrain Single Speed -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Reynolds 520 Butted Cromoly
Suspension Fork
Kona Project Two 29 Disc
Rear Shock
n/a
Drivetrain
Rear Derailleur
n/a
Front Derailleur
n/a
Shift Levers
n/a
Cassette
Joytech 18t
Crank
32t
Bottom Bracket
FSA MegaExo
Chain
KMC Z610
Pedals
Kona JackShit
Wheels
Front Hub
Joytech
Rear Hub
Joytech
Rims
WTB ST i23 TCS
Spokes
Sandvik Stainless 15g fr / 14g rr
Tires
Maxxis Ardent 29x2.25"
Brakes
Brakes
Avid BB7
Brake Levers
Avid FR5
Disk Rotors
Avid G2 Clean Sweep 180mm
Cockpit
Stem
Kona XC/Road Light
Handlebar
Kona XC/BC Riser
Grips
Kona Race Light LOG
Headset
TH ZST No.10
Seat
Saddle
WTB Volt Comp
Seatpost
Kona Thumb w/Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 19" | 21" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.43 mm | 1.38 mm | 1.33 mm |
| Bottom Bracket Height | 318 mm | 318 mm | 318 mm | 318 mm |
| Front Center | 636 mm | 662 mm | 687 mm | 713 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 87 mm | 88 mm | 88 mm | 88 mm |
| Stack | 582 mm | 592 mm | 601 mm | 611 mm |
| Reach | 391 mm | 414 mm | 436 mm | 459 mm |
| Top Tube Length | 570 mm | 595 mm | 620 mm | 646 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 135 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1062 mm | 1088 mm | 1113 mm | 1140 mm |
| Bottom Bracket Drop | 56 mm | 56 mm | 56 mm | 56 mm |
| Standover Height | 728 mm | 758 mm | 788 mm | 818 mm |
| Wheels | 29" | 29" | 29" | 29" |
About this model
UNIT belongs to the Kona Unit model. 20 bikes variations carry this model name so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Overview of components
Fork material
UNIT has a steel fork, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels size
As for the wheels, Kona UNIT 2015, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Kona UNIT is equipped with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
