Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
49cm
155cm - 163cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Reynolds 853 Butted Cromoly
Suspension Fork
Kona Carbon Road Disc
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Tiagra
Front Derailleur
Shimano Tiagra
Shift Levers
Shimano Tiagra
Cassette
Shimano Tiagra 11-32t 10spd
Crank
34/50t
Bottom Bracket
TH 7420
Chain
KMC X10
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Alex CXD6 Disc Wheelset 100x12mm
Rear Hub
Alex CXD6 Disc Wheelset 142x12mm
Rims
Alex CXD6 Disc Wheelset
Spokes
Alex CXD6 Disc Wheelset
Tires
Schwalbe Spicer K-Guard 700x30c
Brakes
Brakes
TRP Spyre
Brake Levers
Shimano Tiagra
Disk Rotors
TRP 140mm
Cockpit
Stem
Kona Road
Handlebar
Kona Road
Grips
Kona Cork Tape
Headset
FSA Custom
Seat
Saddle
Kona Classic Road
Seatpost
Kona Thumb w/Offset 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.51 mm | 1.53 mm | 1.56 mm | 1.58 mm | 1.6 mm |
| Bottom Bracket Height | 269 mm | 269 mm | 271 mm | 271 mm | 273 mm | 273 mm |
| Front Center | 583 mm | 584 mm | 593 mm | 604 mm | 615 mm | 623 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 69 mm | 63 mm | 65 mm | 64 mm | 60 mm | 57 mm |
| Stack | 547 mm | 570 mm | 586 mm | 605 mm | 624 mm | 645 mm |
| Reach | 375 mm | 378 mm | 383 mm | 387 mm | 396 mm | 403 mm |
| Top Tube Length | 525 mm | 540 mm | 555 mm | 570 mm | 585 mm | 605 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72 ° | 72.5 ° | 73 ° |
| Head Tube Length | 115 mm | 135 mm | 165 mm | 175 mm | 195 mm | 215 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm | 430 mm | 430 mm |
| Wheelbase | 998 mm | 999 mm | 1008 mm | 1020 mm | 1034 mm | 1043 mm |
| Bottom Bracket Drop | 76 mm | 76 mm | 74 mm | 74 mm | 72 mm | 72 mm |
| Standover Height | 745 mm | 770 mm | 790 mm | 810 mm | 830 mm | 855 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
About this model
Wheelhouse is part of the Kona Wheelhouse model. There are 2 bikes that carry this model name.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Endurance bikes average price
If you want an acceptable Endurance bike you should know that the average price is 2346$. However, even though the average price of an Endurance bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1599$. Doing a quick comparison, we notice that Wheelhouse price is 46.72% smaller than the average cost of an Endurance bike.
Overview of components
Fork material
Wheelhouse has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
As for the wheels, Kona Wheelhouse 2017, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Wheelhouse comes with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
There are 6 sizes available for this model. Rider height can be anywhere between 155 cm – 191 cm (5.09 ft – 6.27 ft). In conclusion, you won’t have a problem finding one that suits you.
