Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
49cm
155cm - 163cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Reynolds 853 Butted Cromoly
Suspension Fork
Kona Carbon Flat Mount Road Disc
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Tiagra
Front Derailleur
Shimano Tiagra
Shift Levers
Shimano Tiagra
Cassette
Shimano HG500 11-32t 10spd
Crank
Shimano Tiagra, 34/50t
Bottom Bracket
Shimano RS500
Chain
KMC X10
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Alex Boondocks 5 Wheelset 100x12mm
Rear Hub
Alex Boondocks 5 Wheelset 142x12mm
Rims
Alex Boondocks 5 Wheelset
Spokes
Alex Boondocks 5 Wheelset
Tires
Schwalbe Spicer K-Guard 700x30c
Brakes
Brakes
TRP Spyre C
Brake Levers
Shimano Tiagra
Disk Rotors
Tektro TR160 160mm
Cockpit
Stem
Kona Road
Handlebar
Kona Road
Grips
Kona Cork Tape
Headset
FSA Custom
Seat
Saddle
Kona Classic Road
Seatpost
Kona Road w/Offset 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.51 mm | 1.53 mm | 1.57 mm | 1.58 mm | 1.6 mm |
| Bottom Bracket Height | 269 mm | 269 mm | 271 mm | 271 mm | 273 mm | 273 mm |
| Front Center | 583 mm | 584 mm | 595 mm | 604 mm | 615 mm | 623 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 68 mm | 62 mm | 63 mm | 62 mm | 60 mm | 56 mm |
| Stack | 547 mm | 570 mm | 587 mm | 606 mm | 625 mm | 646 mm |
| Reach | 375 mm | 378 mm | 383 mm | 386 mm | 396 mm | 403 mm |
| Top Tube Length | 525 mm | 540 mm | 555 mm | 570 mm | 585 mm | 605 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72 ° | 72.5 ° | 73 ° |
| Head Tube Length | 115 mm | 135 mm | 155 mm | 175 mm | 195 mm | 215 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm | 430 mm | 430 mm |
| Wheelbase | 998 mm | 999 mm | 1010 mm | 1020 mm | 1034 mm | 1043 mm |
| Bottom Bracket Drop | 76 mm | 76 mm | 74 mm | 74 mm | 72 mm | 72 mm |
| Standover Height | 745 mm | 775 mm | 795 mm | 815 mm | 835 mm | 860 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
About this model
Wheelhouse belongs to the Kona Wheelhouse model. Kona launched 2 bikes of this model so far.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Endurance bikes average price
According to our calculations, the average cost of an Endurance bike that is reliable is 2346$. However, this doesn’t mean that if you spend less money on an Endurance bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1799$. Doing a quick comparison, we notice that Wheelhouse price is 30.41% lower than the average cost of an Endurance bike.
Wheelhouse components
Fork material
Wheelhouse has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
The wheels on Wheelhouse are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Kona Wheelhouse is equipped with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
Wheelhouse comes in 6 sizes, that range from 155 cm – 191 cm (5.09 ft – 6.27 ft). In conclusion, finding one for you shouldn’t be a problem.
