Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Groupset Deore, SLX -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 6061 Aluminum Butted
Suspension Fork
Kona P2 Fat Disc
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Deore Shadow
Front Derailleur
Shimano SLX
Shift Levers
Shimano Alivio
Cassette
Shimano HG20 11-34t 9 spd
Crank
24/36t/Guard
Bottom Bracket
FSA ISIS
Chain
KMC Z99
Chain Guide
n/a
Pedals
Wellgo Platform
Wheels
Front Hub
Joytech 135mm
Rear Hub
Joytech 170mm
Rims
Jetset
Spokes
Stainless 14g
Tires
Vee Rubber Mission 26x4.0"
Brakes
Brakes
Tektro Novela Mechanical Disc
Brake Levers
Tektro ML330
Disk Rotors
Tektro 160mm
Cockpit
Stem
Kona XC/Road
Handlebar
Kona Handplant
Grips
Kona SLOG
Headset
TH Internal
Seat
Saddle
Kona Fat
Seatpost
Kona Double Clamp
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 19" | 21" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.46 mm | 1.41 mm | 1.37 mm |
| Bottom Bracket Height | 283 mm | 283 mm | 283 mm | 283 mm |
| Front Center | 639 mm | 663 mm | 689 mm | 716 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 74 mm | 74 mm | 74 mm | 74 mm |
| Stack | 590 mm | 600 mm | 609 mm | 623 mm |
| Reach | 389 mm | 411 mm | 433 mm | 455 mm |
| Top Tube Length | 570 mm | 595 mm | 620 mm | 646 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 115 mm | 125 mm | 135 mm | 150 mm |
| Chainstay Length | 453 mm | 453 mm | 453 mm | 453 mm |
| Wheelbase | 1085 mm | 1110 mm | 1136 mm | 1163 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 717 mm | 721 mm | 725 mm | 730 mm |
| Wheels | 26" | 26" | 26" | 26" |
Model Overview
WO completes the Kona Wo model. Kona released 10 bikes variations of this model so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Fatbike bikes average price
If you want an acceptable Fatbike bike you should know that the average price is 1743$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Fatbike bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
WO components
Wheels
When it comes to wheels, the WO bike is equipped with the 26″ aluminum model. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
Nothing is more important on a bike than its ability to brake properly. Kona WO is equipped with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
