Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Groupset SLX, Deore -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 7005 Aluminum Butted
Suspension Fork
Kona Wo Fat Disc
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano SLX Shadow Plus
Front Derailleur
Shimano Deore
Shift Levers
Shimano Deore
Cassette
Shimano Deore 11-36t 10spd
Crank
22/36t/Guard
Bottom Bracket
RaceFace Ride
Chain
KMC X10
Chain Guide
n/a
Pedals
Wellgo Platform
Wheels
Front Hub
Joytech 150mm
Rear Hub
Joytech 190mm
Rims
Sun Ringle MuleFut
Spokes
Stainless 14g
Tires
Schwalbe Jumbo Jim 26x4.8"
Brakes
Brakes
Shimano Deore
Brake Levers
Shimano Deore
Disk Rotors
Shimano Deore 180mm
Cockpit
Stem
Kona XC
Handlebar
Kona XC/BC Riser
Grips
Kona S-LOG
Headset
FSA No. 57B
Seat
Saddle
Kona Fat
Seatpost
Kona Thumb w/Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.46 mm | 1.4 mm | 1.37 mm |
| Bottom Bracket Height | 283 mm | 283 mm | 283 mm | 283 mm |
| Front Center | 639 mm | 664 mm | 689 mm | 716 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 73 mm | 74 mm | 73 mm | 73 mm |
| Stack | 589 mm | 599 mm | 608 mm | 622 mm |
| Reach | 389 mm | 411 mm | 433 mm | 455 mm |
| Top Tube Length | 570 mm | 595 mm | 620 mm | 646 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 115 mm | 125 mm | 135 mm | 150 mm |
| Chainstay Length | 453 mm | 453 mm | 453 mm | 453 mm |
| Wheelbase | 1085 mm | 1110 mm | 1136 mm | 1163 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 678 mm | 718 mm | 748 mm | 761 mm |
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 152 cm | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 182 cm | 195 cm | 195 cm |
About this model
WO completes the Kona Wo model. Kona released 10 bikes variations of this model so far.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Fatbike bikes average price
Our math shows that the average cost of a dependable Fatbike bike is 1743$. However, even though the average price of a Fatbike bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Kona WO price was 1899$. In conclusion, this bike price is 8.95% higher than the price of the average Fatbike bike.
WO components
Wheels
The wheels on WO are the 26″ aluminum type. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 152 cm – 195 cm (4.99 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
