Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Groupset SX Eagle, NX -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Fat 6061 Aluminum Butted
Suspension Fork
Kona Wo Fat Carbon Disc
Rear Shock
n/a
Drivetrain
Rear Derailleur
SRAM SX-Eagle
Front Derailleur
n/a
Shift Levers
SRAM SX-Eagle
Cassette
SRAM SX-Eagle 11-50t 12spd
Crank
SRAM NX-Eagle Dub Fat, 30t X-Sync Eagle
Bottom Bracket
SRAM DUB PF121
Chain
SRAM SX-Eagle
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Formula 150x15mm
Rear Hub
Formula 197x12mm
Rims
Sun Ringle Mulefut 80 Tubeless Ready
Spokes
Stainless Black 14g
Tires
Vee Tire Snow Avalanche TR Studdable 26x4.8"
Brakes
Brakes
Shimano Hydraulic
Brake Levers
Shimano Hydraulic
Disk Rotors
Shimano RT56 180mm
Cockpit
Stem
Kona XC/BC 35
Handlebar
Kona XC/BC 35
Grips
Kona Key Grip
Headset
FSA No.57B
Seat
Saddle
Kona Fat
Seatpost
Kona XC/BC 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.42 mm | 1.36 mm | 1.28 mm |
| Bottom Bracket Height | 318 mm | 319 mm | 319 mm | 319 mm |
| Front Center | 710 mm | 737 mm | 764 mm | 800 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 81 mm | 80 mm | 80 mm | 80 mm |
| Stack | 642 mm | 647 mm | 654 mm | 658 mm |
| Reach | 432 mm | 456 mm | 481 mm | 516 mm |
| Top Tube Length | 603 mm | 630 mm | 657 mm | 694 mm |
| Seat Tube Angle | 74.7 ° | 74.7 ° | 74.6 ° | 74.6 ° |
| Seat Tube Length | 381 mm | 432 mm | 478 mm | 508 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 120 mm | 125 mm | 130 mm | 135 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm | 418 mm |
| Wheelbase | 1120 mm | 1147 mm | 1174 mm | 1211 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 734 mm | 762 mm | 796 mm | 817 mm |
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 152 cm | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 182 cm | 195 cm | 195 cm |
About this model
Woo belongs to the Kona Woo model. Kona released 4 bikes variations of this model so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Fatbike bikes average price
According to our math, the average price for a trustworthy Fatbike bike is 1743$. However, even though the average price of a Fatbike bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2020 and its price was 2099$. In conclusion, this bike price is 20.42% more expensive than the price of the average Fatbike bike.
Overview of components
Fork material
Woo has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The Woo 2020 bike is equipped with 26″ aluminum wheels when leaving the factory. Being a little smaller, these wheels will fit both small and tall riders. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 152 cm – 195 cm (4.99 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
