Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 100mm -
Fork RockShox Bluto RL
-
Groupset GX, Race Face -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Fat 7005 Aluminum Butted
Suspension Fork
RockShox Bluto RL Solo Air 100mm Tapered
Rear Shock
n/a
Drivetrain
Rear Derailleur
SRAM GX
Front Derailleur
n/a
Shift Levers
SRAM GX
Cassette
SRAM PG1130 11-42t 11spd
Crank
RaceFace Aeffect SL, 28t Narrow/Wide
Bottom Bracket
RaceFace PF121
Chain
SRAM PC1110
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Joytech 150x15mm
Rear Hub
Formula 177x12mm
Rims
Sun Ringle MuleFut
Spokes
Stainless Black 14g
Tires
Maxxis FBF EXO TR 3C 26x4.8"
Brakes
Brakes
SRAM Level T
Brake Levers
SRAM Level T
Disk Rotors
SRAM Centerline 180mm
Cockpit
Stem
Kona XC/BC 35
Handlebar
Kona XC/BC 35
Grips
Kona Key Grip
Headset
FSA No.57B
Seat
Saddle
WTB Volt Comp
Seatpost
Kona XC/BC 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.44 mm | 1.37 mm | 1.29 mm |
| Bottom Bracket Height | 307 mm | 307 mm | 307 mm | 307 mm |
| Front Center | 711 mm | 738 mm | 765 mm | 801 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 80 mm | 80 mm | 79 mm | 80 mm |
| Stack | 641 mm | 646 mm | 650 | 655 mm |
| Reach | 423 mm | 448 mm | 473 mm | 508 mm |
| Top Tube Length | 601 mm | 628 mm | 655 mm | 691 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 381 mm | 432 mm | 478 mm | 508 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 120 mm | 125 mm | 130 mm | 135 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm | 418 mm |
| Wheelbase | 1122 mm | 1149 mm | 1176 mm | 1212 mm |
| Bottom Bracket Drop | 63 mm | 63 mm | 63 mm | 63 mm |
| Standover Height | 723 mm | 753 mm | 783 mm | 803 mm |
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 152 cm | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 182 cm | 195 cm | 195 cm |
About this model
Wozo is a Kona Wozo model. 4 bikes variations carry this model name so far.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Fatbike bikes average price
According to our math, the average price for a trustworthy Fatbike bike is 1743$. However, you could also get a good Fatbike bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Kona Wozo price was 2499$. Doing a quick comparison, we notice that Wozo price is 43.37% more expensive than the average cost of a Fatbike bike.
Overview of components
Fork
The RockShox Bluto RL is included from the factory. It has a travel distance of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
As for the wheels, Kona Wozo 2018, has a 26″ aluminum model. Being a little smaller, these wheels will fit both small and tall riders. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
For your safety, it is important to have quality breaks on your bike. Kona Wozo has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Wozo comes in 4 sizes, that range from 152 cm – 195 cm (4.99 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
