Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Carbon Race by Deda
Suspension Fork
Kona Carbon Race by Deda
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano 105
Front Derailleur
Shimano 105
Shift Levers
Shimano 105
Cassette
Shimano 105 12-25t 10 spd
Crank
50/34t
Bottom Bracket
FSA Mega Evo
Chain
KMC X10
Pedals
N/A
Wheels
Front Hub
Mavic Aksium WTS
Rear Hub
Mavic Aksium WTS
Rims
Mavic Aksium WTS
Spokes
Mavic Aksium WTS
Tires
Mavic Aksium WTS 700x25C
Brakes
Brakes
Shimano 105
Brake Levers
Shimano 105
Disk Rotors
N/A
Cockpit
Stem
Kona Road
Handlebar
Kona Road
Grips
Kona Cork
Headset
Deda
Seat
Saddle
Selle Italia X1
Seatpost
Kona Road
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 53cm | 56cm | 59cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.42 mm | 1.5 mm | 1.47 mm | 1.48 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm |
| Front Center | 576 mm | 588 mm | 594 mm | 600 mm | 609 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 67 mm | 65 mm | 65 mm | 56 mm | 60 mm |
| Stack | 521 mm | 548 mm | 573 mm | 583 mm | 593 mm |
| Reach | 377 mm | 385 mm | 383 mm | 396 mm | 402 mm |
| Top Tube Length | 522 mm | 537 mm | 552 mm | 572 mm | 587 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 73.5 ° | 73 ° | 72 ° |
| Seat Tube Length | 470 mm | 510 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 71.5 ° | 72 ° | 72 ° | 73 ° | 73 ° |
| Head Tube Length | 120 mm | 147 mm | 173 mm | 180 mm | 190 mm |
| Chainstay Length | 409 mm | 409 mm | 412 mm | 412 mm | 415 mm |
| Wheelbase | 972 mm | 984 mm | 993 mm | 1002 mm | 1010 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 752 mm | 780 mm | 800 mm | 814 mm | 836 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
ZING SUPREME is a Kona Zing model. There are 12 bikes that carry this model name.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Race bikes average price
According to our calculations, the average cost of a Race bike that is reliable is 3350$. However, this doesn’t mean that if you spend less money on a Race bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When leaving the production line, the ZING SUPREME model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The ZING SUPREME has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
