Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Fork Suntour NEX -
Groupset Deore, Tourney -
Suspension Hardtail -
Motor Bafang hub-drive -
Battery PHYLION SF-06S 522Wh -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUMINIUM PERFORMANCE
Suspension Fork
SR SUNTOUR NEX
Rear Shock
NO
Drivetrain
Rear Derailleur
SHIMANO DEORE M592
Front Derailleur
SHIMANO TOURNEY TY710
Shift Levers
SHIMANO EF505
Cassette
SHIMANO HG31 11-32T
Crank
SHIMANO TOURNEY TY501
Bottom Bracket
NO
Chain
KMC HV700
Pedals
FP-910
Wheels
Front Hub
GL-B43F-DS
Rear Hub
BAFANG G120.250.DC
Rims
KROSS
Tires
MITAS FLASH V66 47-622
Brakes
Brakes
SHIMANO MT200
Brake Levers
SHIMANO EF505
Cockpit
Stem
ALUMINIUM
Handlebar
STEEL 600MM
Headset
FP-H805A; 1 1/8"
Seat
Saddle
KROSS D2201
Seatpost
ALUMINIUM 27,2x350
Motor & Battery
Motor
BAFANG G120
Battery
PHYLION SF-06S 522Wh
Remote
BAFANG HMI DP E12.UART
Charger
43V / 2A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.584 mm | 1.544 mm | 1.488 mm |
| Front Center | 631 mm | 641 mm | 656 mm |
| Rake | 40 mm | 40 mm | 40 mm |
| Trail | 84 mm | 84 mm | 84 mm |
| Stack | 610 mm | 610 mm | 610 mm |
| Reach | 385 mm | 395 mm | 410 mm |
| Top Tube Length | 560 mm | 570 mm | 585 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 140 mm | 140 mm | 140 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1084 mm | 1094 mm | 1109 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
TRANS HYBRID completes the Kross E Trans model. Kross released 41 e-bikes variations of this model so far.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Hybrid e-bikes average price
According to our math, the average price for a trustworthy Hybrid e-bike is 2480$. However, you could also get a good Hybrid e-bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
TRANS HYBRID components
Fork
This e-bike has the Suntour NEX fork installed. The fork’s travel is mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
As for the wheels, Kross TRANS HYBRID 2021, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The TRANS HYBRID has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
