Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset microSHIFT Acolyte, Shimano -
Suspension Hardtail -
Motor Shimano 250W 40Nm mid-drive -
Battery SIMPLO 14AH/504WH -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUMINIUM PERFORMANCE
Suspension Fork
SR SUNTOUR NEX-E25
Drivetrain
Rear Derailleur
MICROSHIFT ACOLYTE M5180M
Shift Levers
MICROSHIFT ACOLYTE
Cassette
11-32T
Crank
SHIMANO STEPS
Bottom Bracket
STEPS, press-fit
Chain
YBN S8E
Wheels
Front Hub
GL-B43F-DS
Rear Hub
GL-B43F-DS
Rims
KROSS ALUMINIUM 622X19
Tires
WANDA G5001 28X1,75
Brakes
Brakes
Front: SHIMANO MT200, Rear: SHIMANO MT200
Brake Levers
SHIMANO MT200
Cockpit
Handlebar
ALUMINIUM 660 MM 31.8
Grips
HERRMANS OXY
Headset
FP-H856B2;1-1/8"-1.5"
Seat
Saddle
YIBOTONG YBT-K607
Seatpost
ALUMINIUM 31,6X350MM
Motor & Battery
Motor
SHIMANO E5000
Battery
SIMPLO 14AH/504WH
