Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Deore, Altus -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Tektro Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
26" Alloy 6061 COUNTRY STAR / K-7680
Suspension Fork
Suntour NEX coil 26" 63mm
Drivetrain
Rear Derailleur
Shimano Altus M310-7/8
Shift Levers
Shimano EF500-7 4F
Cassette
Shimano TZ500-7 / 14-34
Crank
Shimano Tourney T501 42-34-24T
Chain
Shimano HG40-8
Chain Guide
Horn Catena Compact 44T
Pedals
KTM Line Onroad BF
Wheels
Rims
KTM Line - Shimano DH-C3000-3 32H NT / KTM 26" City 32H; 559x19 / Richman 2.0 INOX, silver
Tires
Front: Vittoria Randonneur 47-559 Reflex, Rear: Vittoria Randonneur 47-559 Reflex
Brakes
Brakes
Tektro 855AL
Cockpit
Stem
KTM Line 17°
Handlebar
KTM Line rizer 20
Headset
Ritchey OE Zero Logic 1.1/8"
Seat
Saddle
Selle Royal Rio 12
Seatpost
KTM Line 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
