Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 63mm -
Fork Suntour NX 1
-
Groupset SX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
28" Alloy 6061 ONROAD DISC / T-3540
Suspension Fork
Suntour NX1 coil LO 63mm
Drivetrain
Rear Derailleur
SRAM SX Eagle 12speed
Shift Levers
SRAM SX Eagle Trigger
Cassette
SRAM PG-1210 EAGLE / 11-50
Crank
SRAM S650 Eagle 38T
Chain
SRAM NX Eagle
Chain Guide
SKS Chainblade 42/44T
Pedals
KTM Comp Onroad SB
Wheels
Rims
KTM Line - Shimano DH-3D37 CL 32H 100 QR / KTM 28" Casual 32H; 622x19 / Richman 2.0 INOX, black
Brakes
Brakes
Shimano MT200 / MT200 2-Piston
Cockpit
Stem
KTM Line 17°
Handlebar
KTM Line rizer20 640mm
Headset
Ritchey OE Zero Logic 1.1/8"
Seat
Saddle
Selle Royal Essenza Moderate
Seatpost
KTM Line 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Front Center | 636 mm | 647 mm | 658 mm | 674 mm |
| Top Tube Length | 580 mm | 590 mm | 600 mm | 615 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 460 mm | 510 mm | 560 mm | 600 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 137 mm | 155 mm | 174 mm | 190 mm |
| Chainstay Length | 452 mm | 452 mm | 452 mm | 452 mm |
| Wheelbase | 1082 mm | 1093 mm | 1104 mm | 1119 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm |
| Standover Height | 789 mm | 819 mm | 853 mm | 878 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
