KTM MAC AERA FS ELITE LFC 2025
2025 E-bike
Estimate price |
6,881$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 100mm -
Fork Suntour XCR Air
-
Groupset CUES -
Suspension Full -
Motor Bosch 600W 85Nm mid-drive -
Battery Bosch PowerTUBE 800Wh horizontal -
Drivetrain 1 × 10 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Macina Aera Perf. Carbon VPP100 UDH PT800 Bosch BDU38/T5880
Suspension Fork
Suntour XCR34X Air 27,5" 2CR 100mm taper
Rear Shock
Suntour EDGE-EVO 2CR 190x45
Drivetrain
Shift Levers
Shimano CUES U6000-10 display
Cassette
Shimano LG400-10 / 11-48
Crank
KTM E-COMP2 ISIS 170mm Q8
Bottom Bracket
Bosch, press-fit
Chain
Shimano LG500
Pedals
MTB-Pedal flat VPE-527 alloy
Wheels
Rims
KTM Line - Shimano TC500B CL 32H 110-15TA, Ryde Rival30 32H 584x30C, DT Champion 2.0 black \ KTM Line - Shimano TC600B CL 32H 148-12TA, Ryde Rival30 32H 584x30C, DT Alpine II 2.34 black
Tires
Front: Schwalbe Johnny Watts Perf. Folding DD 65-584 Reflex, Rear: Schwalbe Johnny Watts Perf. Folding DD 65-584 Reflex
Brakes
Brakes
Shimano MT402 (3-F) / MT420 4-Piston
Cockpit
Stem
KTM adjust. 0-60° ICR
Handlebar
KTM TEAM II rizer15 700mm
Grips
Ergon GP1 Evo
Headset
Acros headsetcover OD62 Phyton
Seat
Saddle
Selle Royal Lookin Evo
Seatpost
KTM Line II dropper 30.9 T:100
Motor & Battery
Motor
Bosch PERFORMANCE CX BDU3840 - 25km/h / 85Nm
Battery
Bosch PowerTUBE 800Wh horizontal
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.677 mm | 1.662 mm | 1.673 mm | 1.643 mm |
| Bottom Bracket Height | 335 mm | 315 mm | 315 mm | 315 mm |
| Front Center | 664 mm | 695 mm | 693 mm | 708 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 96 mm | 96 mm | 89 mm | 89 mm |
| Stack | 624 mm | 658 mm | 672 mm | 680 mm |
| Reach | 372 mm | 396 mm | 401.6 mm | 414 mm |
| Top Tube Length | 575 mm | 610 mm | 620 mm | 635 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 400 mm | 460 mm | 510 mm | 560 mm |
| Head Tube Angle | 68 ° | 68 ° | 69 ° | 69 ° |
| Head Tube Length | 160 mm | 155 mm | 165 mm | 174 mm |
| Chainstay Length | 505 mm | 530 mm | 530 mm | 530 mm |
| Wheelbase | 1168 mm | 1222 mm | 1220 mm | 1235 mm |
| Bottom Bracket Drop | 20 mm | 40 mm | 40 mm | 40 mm |
| Standover Height | 445 mm | 448 mm | 448 mm | 448 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
