KTM MACINA CROSS CX 625 2025
2025 E-bike
Estimate price |
4,128$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 63mm -
Fork Suntour NX 1
-
Groupset Altus -
Suspension Hardtail -
Motor Bosch 600W 85Nm mid-drive -
Battery Bosch PowerTUBE 625Wh horizontal -
Drivetrain 1 × 8 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Macina PTS Offroad 27.5" Al 6061; PT625Wh Bosch Gen.4/T-1270
Suspension Fork
Suntour NX1 coil LO 63mm
Drivetrain
Shift Levers
Shimano Altus M315-8 display
Cassette
Shimano HG400-8 / 11-40
Crank
KTM E-COMP ISIS 170mm Q16
Bottom Bracket
Bosch, press-fit
Chain
Shimano HG40-8
Pedals
MTB-Pedal VP-195E alloy
Wheels
Rims
KTM Line - Shimano Deore M6000 CL 32H 100-5QR, Ryde Rival Sport 32H 622x25C, DT Champion 2.0 black \ KTM Line - Shimano Deore M6000 CL 32H 135-5QR, Ryde Rival Sport 32H 622x25C, DT Alpine II 2.34 black
Tires
Front: Schwalbe Smart Sam SBC K-Guard 47-622 Reflex, Rear: Schwalbe Smart Sam SBC K-Guard 47-622 Reflex
Brakes
Brakes
Shimano MT200 / MT200 2-Piston
Cockpit
Stem
KTM COMP 17°
Handlebar
KTM COMP low rizer 640mm
Grips
KTM COMP Ergo Lock
Headset
KTM TEAM Trekking 1.1/8"-1.5" angle limit
Seat
Saddle
Selle Royal Essenza Athletic
Seatpost
KTM COMP 30.9/300
Motor & Battery
Motor
Bosch PERFORMANCE CX BDU3741 - 25km/h / 85Nm
Battery
Bosch PowerTUBE 625Wh horizontal
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.515 mm | 1.517 mm | 1.524 mm |
| Front Center | 639 mm | 662 mm | 671 mm |
| Rake | 41 mm | 48 mm | 41 mm |
| Trail | 79 mm | 72 mm | 79 mm |
| Stack | 606 mm | 622 mm | 640 mm |
| Reach | 400 mm | 410 mm | 420 mm |
| Top Tube Length | 578 mm | 593 mm | 608 mm |
| Seat Tube Angle | 73.6 ° | 73.6 ° | 73.6 ° |
| Seat Tube Length | 460 mm | 510 mm | 560 mm |
| Head Tube Angle | 70.6 ° | 70.6 ° | 70.6 ° |
| Head Tube Length | 137 mm | 155 mm | 174 mm |
| Chainstay Length | 452 mm | 452 mm | 452 mm |
| Wheelbase | 1084 mm | 1107 mm | 1116 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Standover Height | 481 mm | 481 mm | 481 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
