Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Nexus -
Suspension Rigid -
Motor Bosch 600W 65Nm mid-drive -
Battery Bosch PowerPACK 500Wh -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KTM Multi 24" alloy
Suspension Fork
24" alloy cargo
Drivetrain
Shift Levers
Shimano Nexus 5 Revoshifter
Cassette
Gates rear-sprocket 34T Nexus 5
Crank
KTM E-LINE BNI 170mm Q16
Chain
Gates drive-belt 143T CDX
Chain Guide
KTM type for Multi
Pedals
MTB-Pedal flat VPE-527 alloy
Wheels
Rims
KTM Line - Shimano Deore M6010 CL 36H 100-15TA / Ryde Andra29 36H 507x29C / DT Alpine II 2.34 black
Tires
Front: Continental Air King 60-507 Reflex, Rear: Continental Air King 60-507 Reflex
Brakes
Brakes
Shimano MT402 (3-F) / MT420 4-Piston
Cockpit
Stem
Ergotec HighCarisma 50
Handlebar
Ergotec Riserbar 50 -780mm
Headset
Acros AICR internal 1.1/8"-1.5" angle limit
Seat
Saddle
Selle Royal Essenza EPTech
Seatpost
KTM COMP II 34.9 / 350
Motor & Battery
Motor
Bosch PERFORMANCE Gen.3 - 25km/h / 65Nm
Battery
Bosch PowerPACK 500Wh
Charger
Bosch STANDARD Charger 4A
Fit data
Geometry
