KTM MACINA RACE 572 2025
2025 E-bike
Estimate price |
3,722$
Weight | 22.3 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork Suntour XCM
-
Groupset Alivio -
Suspension Hardtail -
Motor Bosch 600W 85Nm mid-drive -
Battery Bosch PowerTUBE 500Wh hor. -
Drivetrain 1 × 9 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Macina MTB 27.5" Alloy6061; PT500Wh Bosch Gen.4 / M-1776
Suspension Fork
Suntour XCM 32 coil 27.5" NLO 100mm 15x100 taper
Drivetrain
Rear Derailleur
Shimano Alivio M3100-9 SGS shadow
Shift Levers
Shimano Alivio M3100-9 display
Cassette
Shimano HG201-9 / 11-36
Crank
KTM E-COMP ISIS 170mm Q16
Bottom Bracket
Bosch, press-fit
Chain
Shimano E6070-9 e-bike
Pedals
MTB-Pedal VP-195E alloy
Wheels
Rims
KTM Line - Shimano MT400 CL 32H 100-15TA / Ryde Rival30 32H 584x30C / DT Champion 2.0 black
Tires
Front: Schwalbe Smart Sam K-Guard 57-584, Rear: Schwalbe Smart Sam K-Guard 57-584
Brakes
Brakes
Shimano MT200 / MT200 2-Piston
Cockpit
Stem
KTM COMP II 7°
Handlebar
KTM COMP II rizer15 700mm
Headset
KTM Team drop/in 1.1/8"-1.5"
Seat
Saddle
KTM Line Sport
Seatpost
KTM COMP II 30.9/350
Motor & Battery
Motor
Bosch PERFORMANCE CX Gen.4 - 25km/h / 85Nm
Battery
Bosch PowerTUBE 500Wh hor.
Charger
Bosch COMPACT Charger 2A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.508 mm | 1.514 mm | 1.48 mm |
| Bottom Bracket Height | 308 mm | 308 mm | 308 mm |
| Front Center | 637 mm | 637 mm | 657 mm |
| Rake | 40 mm | 40 mm | 39 mm |
| Trail | 90 mm | 87 mm | 88 mm |
| Stack | 588 mm | 595 mm | 607 mm |
| Reach | 390 mm | 393 mm | 410 mm |
| Top Tube Length | 570 mm | 575 mm | 595 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 400 mm | 430 mm | 480 mm |
| Head Tube Angle | 69.5 ° | 70 ° | 70 ° |
| Head Tube Length | 120 mm | 125 mm | 137 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1078 mm | 1078 mm | 1098 mm |
| Bottom Bracket Drop | 47 mm | 47 mm | 47 mm |
| Standover Height | 732 mm | 736 mm | 752 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
