Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork Suntour XCM
-
Groupset CUES -
Suspension Hardtail -
Motor Bosch 600W 50Nm mid-drive -
Battery Bosch PowerPACK 500Wh -
Drivetrain 1 × 9 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Macina MTB 29" Alloy 6061; UC-PP500Wh Bosch Gen.3 / M-9680
Suspension Fork
Suntour XCM coil 29" HLO 100mm
Drivetrain
Rear Derailleur
menic SHIMANO ARDU4000GS 9-Speed, Shadow Design, CUES, Direct Attachment, Top Normal, 46T-Max/11T-Min
Shift Levers
razeni SL R SHIMANO ASLU40009RA Right, 9-Speed, Clamp Band, CUES, w/Optical gear display
Cassette
9-kazeta SHIMANO ACSLG3009146 11-46T CUES
Crank
KTM LINE BNI 170mm Q16
Bottom Bracket
Bosch, press-fit
Chain
Shimano LG500
Pedals
MTB-Pedal VPE-537 steel
Wheels
Rims
KTM Line - Shimano Acera M3050 CL 32H 100-5QR / Remerx RX2030 Enduro Plus 32H 622x30C / DT Champion 2.0 silver
Brakes
Brakes
Shimano MT200 / MT200 2-Piston
Cockpit
Stem
KTM Comp 7°
Handlebar
KTM Comp rizer15 700mm
Headset
Ritchey OE Zero Logic 1.1/8"
Seat
Saddle
KTM Line Hybrid
Seatpost
KTM Comp 30.9/400
Motor & Battery
Motor
Bosch ACTIVE PLUS Gen.3 - 25km/h / 50Nm
Battery
Bosch PowerPACK 500Wh
Charger
Bosch COMPACT Charger 2A
