Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Nexus -
Suspension Rigid -
Drivetrain Internally Geared Hub -
Brakes Rim
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
28" AL6061 CITY TOURELLA/DELUXE LADY C7500-L
Suspension Fork
Rigid steel 28"
Drivetrain
Shift Levers
Shimano NEXUS-7
Cassette
Shimano 19
Crank
LASCO RCF4 38
Chain
KMC Z1 1/2"x3/32"
Wheels
Rims
KTM Line - Shimano DHC30003 36H Nut / REMERX DRAGON 36H 622x19 / RM 2.0 INOX silver
Brakes
Brakes
Tektro 855AL V-Br
Cockpit
Stem
KTM Line 25.4 180mm
Handlebar
KTM Line Riser 70 BS50 600mm
Headset
Head set NECO H129CPM D:1-1/8"", H:20mm
Seat
Saddle
Selle Royal Odina
Seatpost
KTM Line 27,2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Bottom Bracket Height | 285 mm | 271 mm | 271 mm |
| Front Center | 602 mm | 653 mm | 673 mm |
| Top Tube Length | 572 mm | 599 mm | 619 mm |
| Seat Tube Angle | 72 ° | 71 ° | 71 ° |
| Seat Tube Length | 430 mm | 460 mm | 510 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 454 mm | 464 mm | 464 mm |
| Wheelbase | 1051 mm | 1109 mm | 1129 mm |
| Bottom Bracket Drop | 51 mm | 65 mm | 65 mm |
| Standover Height | 368 mm | 449 mm | 448 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 160 cm | 166 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm |
About this model
TOURELLA belongs to the Ktm Tourella model. 3 bikes variations carry this model name so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Touring bikes
If you want to purchase a solid Touring bike, it is important to know that the average cost is 1007$. However, even if your budget is less than the average, you might still be able to get a top-quality Touring bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2021 and its price was 848$. Doing a quick comparison, we notice that TOURELLA price is 18.75% smaller than the average cost of a Touring bike.
Average weight for Touring bikes
On a deeper look, we notice that the average weight of a Touring bike is 13.35 kg (29.43 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
TOURELLA weighs 16.3 kg (35.94 lbs) and is much heavier than the average. In other words, this model is 22.1% heavier than the average Touring bike.
Overview of components
Fork material
The fork is made out of steel, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels size
When leaving the production line, the TOURELLA model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. KTM TOURELLA is equipped with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
KTM TOURELLA bike has 3 sizes, in the range of 151 cm – 179 cm (4.95 ft – 5.87 ft). In conclusion, finding one for you shouldn’t be a problem.
