Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 100mm -
Fork RockShox Judy Silver TK
-
Groupset 105 Di2, Deore -
Suspension Hardtail -
Drivetrain 1 × 12 Electronic -
Brakes Shimano 105 Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Myroon 29" Performance Carbon UDH / M-2866
Suspension Fork
RockShox Judy Silver TK 29" 100mm remote 15x110 taper
Drivetrain
Shift Levers
Shimano 105 R7120/R7170
Cassette
Shimano Deore M6100-12 / 10-51
Crank
Shimano MT511-12 32T
Chain
Shimano M6100-12
Wheels
Rims
KTM Line - Shimano TC500B CL 32H 110-15TA, Ryde Rival26 32H 622x26C, DT Champion 2.0 black \ KTM Line - Shimano TC500B CL 32H 148-12TA, Ryde Rival26 32H 622x26C, DT Champion 2.0 black
Tires
Front: Maxxis Rekon Race EXO Wire 57-622, Rear: Maxxis Rekon Race EXO Wire 57-622
Brakes
Brakes
Shimano 105 R7020/RS785
Cockpit
Stem
KTM TEAM MTB 7°
Handlebar
KTM COMP II Road 440mm
Grips
KTM tape
Headset
Acros AICR internal 1.1/8"-1.5" angle limit
Seat
Saddle
KTM Line Sport
Seatpost
KTM COMP 27.2/400
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.398 mm | 1.363 mm | 1.333 mm | 1.304 mm |
| Bottom Bracket Height | 304 mm | 304 mm | 304 mm | 304 mm |
| Front Center | 671 mm | 692 mm | 713 mm | 734 mm |
| Rake | 44 mm | 43 mm | 44 mm | 44 mm |
| Trail | 93 mm | 94 mm | 93 mm | 93 mm |
| Stack | 594 mm | 604 mm | 613 mm | 622 mm |
| Reach | 425 mm | 443 mm | 460 mm | 477 mm |
| Top Tube Length | 590 mm | 610 mm | 630 mm | 650 |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 380 mm | 430 mm | 480 mm | 530 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1092 mm | 1113 mm | 1134 mm | 1155 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 761 mm | 775 mm | 803 mm | 832 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
