Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 40mm -
Fork Suntour GVX
-
Groupset Apex AXS -
Suspension Hardtail -
Drivetrain 1 × 12 Electronic -
Brakes SRAM Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon UD SL
Suspension Fork
Suntour GVX32-S 12x100mm 700C 40mm travel
Drivetrain
Rear Derailleur
SRAM Apex XLPR AXS, 12s
Shift Levers
SRAM Apex ETAP AXS D1
Cassette
SRAM PG 1231 XPLR 11-44T 12s
Crank
SRAM Apex D1 Dub Wide 40T 170mm (XS,S), 172,5mm (M,L), 175mm (XL,XXL)
Bottom Bracket
SRAM DUB Press Fit 86.5 Road
Chain
SRAM Apex 12s
Pedals
VP-335 Clips&Strap
Wheels
Rims
DT Swiss G1800 Spline
Tires
WTB Raddler TCS LIGHT 700x44c black 60TPI
Brakes
Brakes
SRAM Paceline 160mm/160mm Centerlock
Cockpit
Stem
Lapierre alloy, internal routing, Ø: 31.8mm, 80mm (XS/S) 90mm (M) 100mm (L) 110mm (XL)
Handlebar
Lapierre alloy gravel bar, Width: 420mm (XS,S), 440mm (M,L), 460mm (XL,XXL), Drop: 114mm, Reach: 70mm, Rise: 12mm, Flare: 12°
Grips
Lapierre Tape
Seat
Saddle
Fizik Terra Argo X7 150mm
Seatpost
Lapierre alloy, Ø: 27.2mm, L: 350mm
