Lapierre e-Urban 3.5 2024
2024 E-bike
Estimate price |
3,373$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 50mm -
Fork Suntour NEX
-
Groupset CUES -
Suspension Hardtail -
Motor Bosch 250W 40Nm mid-drive -
Battery Bosch Active line “25kph” / Intube battery 500Wh / LED Remote -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
e-Urban Bosch Integrated
Suspension Fork
SR Suntour NEX-E25 DS Tapered QR 9x100 700c 50mm travel
Drivetrain
Rear Derailleur
Shimano CUES U3020 9s Shadow
Shift Levers
Shimano CUES U4000 9s
Cassette
Shimano CUES LG300 11-36T 9s
Crank
Samox 170mm + 38T steel chainring
Bottom Bracket
Bosch, press-fit
Chain
Shimano CUES LG500 9/10/11s
Pedals
VP VPE-461
Wheels
Rims
Ryde 27.5" ECO21 32H, 584x21C, Black Eyelets
Tires
SCHWALBE BIG APPLE 50-622
Brakes
Brakes
Shimano RT10 180mm / 160mm Center Lock
Brake Levers
Shimano MT200 2 Pistons
Cockpit
Stem
Lapierre adjustable, 0-70°, Ø: 31.8mm, Length : 85mm
Handlebar
Lapierre alloy Width: 640mm, Rise: 25mm, Backsweep : 35°, Ø: 31.8mm
Grips
XLC Ergonomic grips
Seat
Saddle
Selle Royal Wave
Seatpost
Lapierre Aluminium 6061 Ø: 31.6mm, Longueur : 350mm, Offset : 15mm
Motor & Battery
Motor
Bosch Active line “25kph” / Intube battery 500Wh / LED Remote
Battery
Bosch Active line “25kph” / Intube battery 500Wh / LED Remote
