Lapierre Overvolt AM 10.8 2025
2025 E-bike
Estimate price |
10,470$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 170mm -
Fork RockShox ZEB Ultimate
-
Groupset GX Eagle Transmission -
Suspension Full -
Motor Bosch 600W 85Nm mid-drive -
Battery Bosch Performance line CX “25kph” BDU384 / Powertube Horizontal 800Wh / Kiox 300 -
Drivetrain 1 × 12 Electronic -
Brakes SRAM Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Suprême 5 alloy
Suspension Fork
RockShox ZEB Ultimate Charger 3.1 RC2 15x110 29”170mm travel 44mm offset
Rear Shock
RockShox Super Deluxe Ultimate RC2T 205x60mm Trunnion/30x8mm
Drivetrain
Rear Derailleur
SRAM GX Eagle AXS T-TYPE 12s
Shift Levers
SRAM AXS Pod 12s
Cassette
SRAM XS1275 T-TYPE 10-52T 12s
Crank
E13 Helix Core 160mm + SRAM XX T-TYPE 34T 55CL
Chain
SRAM GX T-TYPE 12s
Pedals
XLC by VP
Wheels
Rims
DT Swiss HX1501 Spline One front: 622x30, rear: 584x30, XD Driver
Tires
Front : Continental Kryptotal F Enduro Super soft 60-622 Rear : Continental Kryptotal R Enduro Soft 60-584
Brakes
Brakes
SRAM HS2 220mm/200mm 6 bolts
Brake Levers
SRAM Maven Bronze 4 pistons
Cockpit
Stem
Lapierre Thirty Five alloy 0°, Ø: 35mm, L: 35mm (S/M), 45mm (L/XL)
Handlebar
Lapierre Thirty Five Alloy 6061 DB, Width: 800mm, Rise: 30mm, Backsweep: 8°, Upsweep: 6°, Ø: 35mm
Grips
Lapierre Grips S/M: Small Diameter L/XL: Large Diameter
Seat
Saddle
Selle Royal Terra Ridon X3 145mm Kium Mobius
Seatpost
Lapierre dropper by JD YSI05, Ø: 31.6mm, travel 125mm (S), 150mm (M), 170mm (L), 200mm (XL)
Motor & Battery
Motor
Bosch Performance line CX “25kph” BDU384 / Powertube Horizontal 800Wh / Kiox 300
Battery
Bosch Performance line CX “25kph” BDU384 / Powertube Horizontal 800Wh / Kiox 300
