Lapierre Overvolt AM 7.7 2024
2024 E-bike
Estimate price |
7,561$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 170mm -
Fork RockShox ZEB
-
Groupset GX, X01 -
Suspension Full -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch Performance line CX “25kph” / Intube battery 750Wh/ Purion 200 -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Overvolt AM Bosch Supreme 5 alloy
Suspension Fork
RockShox ZEB Base RUSH RC 29” 15x110 DebonAir™ 170mm 44mm offset
Rear Shock
RockShox Deluxe Select R 230x60mm
Drivetrain
Rear Derailleur
SRAM Gx Lunar Eagle 12spd
Shift Levers
SRAM X01 Single Click Eagle 12spd
Cassette
SRAM PG1230 Eagle 11-50 12spd
Crank
E13 E-spec Plus Bosch CX Gen4 160mm (S,M) , 165mm (L,XL) + SRAM X-SYNC 2 EAGLE 34T
Bottom Bracket
Bosch, press-fit
Chain
SRAM NX Eagle Powerlock
Pedals
VP VPE-527
Wheels
Rims
Lapierre eAM+ alloy 32H, front: 622x33 J-bend, rear: 584x35 J-bend Tubeless Ready
Tires
Front: Schwalbe MAGIC MARY Evo, Super Trail, TLE, ADDIX Ultra Soft, 62-622, 67TPI Rear: Schwalbe BIG BETTY, Super Trail, TLE, ADDIX Soft, 65-584, 67TPI”
Brakes
Brakes
SRAM Centerline 220mm/200mm 6 bolts
Cockpit
Stem
Lapierre Thirty Five alloy 0°, Ø: 35mm, L: 35mm (S/M), 45mm (L/XL)
Handlebar
Lapierre Thirty Five Alloy 6061 DB, Width: 800mm, Rise: 30mm, Backsweep: 8°, Upsweep: 6°, Ø: 35mm
Grips
Lapierre grips anodized, S/M: small diameter, L/XL: large diameter
Seat
Saddle
Fizik Terra Aidon X5 145mm
Seatpost
Lapierre dropper, Ø: 31.6mm, travel 100mm (S), 130mm (M), 150mm (L,XL) + Shimano lever
Motor & Battery
Motor
Bosch Performance line CX “25kph” / Intube battery 750Wh/ Purion 200
Battery
Bosch Performance line CX “25kph” / Intube battery 750Wh/ Purion 200
