Lapierre Overvolt AM 9.7 2024

2024 E-bike
Estimate price | 10,469$
E-bike
Open compare Use advisor
Lapierre Overvolt Am 9.7 2024

Bike details

Overview

Key information split into simple groups.

Bike summary

  • Category
  • Frame Aluminum
  • Wheels 27.5"
  • Travel Front 170mm
  • Fork Fox Factory Float 38
  • Groupset X01 Eagle, e*thirteen
  • Suspension Full
  • Motor Bosch 250W 85Nm mid-drive
  • Battery Bosch Performance Line CX Gen4 750Wh PowerTube / LED Remote + KIOX 300
  • Drivetrain 1 × 12
  • Brakes Hydraulic Disc

Parts list

Components

Main components, grouped by system.

Bike components

Frame

Frame

Overvolt AM Bosch Supreme 5 alloy

Suspension Fork

Fox Float 38 Factory 29'' 15x110, 170mm travel, 44mm offset / 3-position lever

Rear Shock

Fox Float X Factory 230x60mm 2-position lever

Drivetrain

Rear Derailleur

SRAM X01 Eagle, 12s

Shift Levers

SRAM X01 Single click Eagle 12s

Cassette

SRAM XG1275 10-52T 12s

Crank

E13 E-spec+ Race Carbon 160mm (S/M) / 165mm (L/XL) + SRAM Eagle steel ring 34T

Bottom Bracket

Bosch, press-fit

Chain

SRAM XX1 Black Eagle Powerlock 12s

Pedals

VP VPE-527

Wheels

Rims

E-DEEMAX S 30 29" (front), E-DEEMAX S 35 27,5" XD driver (rear)

Tires

Schwalbe, front: 62-622, MAGIC MARY Evo, 67TPI, Super Trail, Addix Ultra soft, TR / rear: 65-584, BIG BETTY, 67TPI, Super Trail, Addix soft, TR

Brakes

Brakes

SRAM Centerline 220mm/200mm 6 bolts

Brake Levers

SRAM Code RSC 4 pistons

Cockpit

Stem

Lapierre alloy CNC, Ø: 31.8mm, L: 40mm (S/M), 45mm (L/XL)

Handlebar

Race Face SIXC Carbon W: 785mm R: 19mm Ø: 31.8mm

Grips

Lapierre grips anodized, S/M: small diameter, L/XL: large diameter

Seat

Saddle

Fizik Terra Aidon X3 145mm

Seatpost

JD dropper "Rad travel adjust", Ø: 31.6mm, travel: 125mm (S), 150mm (M), 170mm (L/XL) + MMX Remote

Motor & Battery

Motor

Bosch Performance Line CX Gen4 750Wh PowerTube / LED Remote + KIOX 300

Battery

Bosch Performance Line CX Gen4 750Wh PowerTube / LED Remote + KIOX 300
