Lapierre Overvolt TR 6.7 2024
2024 E-bike
Estimate price |
6,397$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Fork RockShox
-
Groupset CUES, e*thirteen -
Suspension Full -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch Performance line CX “25kph” / Intube battery 750Wh/ Purion 200 -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Overvolt TR Bosch Supreme 5 alloy
Suspension Fork
RockShox Psylo Silver RC 29’’ 15x110 140mm 44mm offset
Rear Shock
Lapierre Shock Metric 210x50mm
Drivetrain
Rear Derailleur
Shimano CUES U6000 10/11s Shadow+
Shift Levers
Shimano CUES U6000 11s
Cassette
Shimano CUES LG400 11-50T 11s
Crank
E13 E-spec Plus Bosch CX Gen4 160mm (S/M) / 165mm (L/XL) + E13 E-spec alloy chainring 34T
Bottom Bracket
Bosch, press-fit
Chain
Shimano CUES LG500 9/10/11s
Pedals
VP VPE-527
Wheels
Rims
Lapierre 29" eAM+ 32H, 622x30 Tubeless Ready
Tires
Front : MAXXIS Minion DHF EXO TR 29x2.50 WT 60TPI Rear : MAXXIS Agressor EXO TR 29x2.50 60TPI
Brakes
Brakes
Shimano SMRT30 203mm (front) / RTEM300 203mm (rear) centerlock
Brake Levers
Shimano M4100 4 (front) / 2 (rear) pistons
Cockpit
Stem
Lapierre alloy CNC, Ø: 31.8mm, L: 45mm (S,M), 50mm (L,XL)
Handlebar
Lapierre Alloy 6061 DB, Width: 760mm, Rise: 15mm (S/M) 30mm (L,XL), Ø: 31.8mm
Grips
Lapierre grips anodized, S/M: small diameter, L/XL: large diameter
Seat
Saddle
Selle Royal Vivo Men
Seatpost
Lapierre dropper, Ø: 31.6mm, travel 100mm (S), 130mm (M), 150mm (L,XL) + Shimano lever
Motor & Battery
Motor
Bosch Performance line CX “25kph” / Intube battery 750Wh/ Purion 200
Battery
Bosch Performance line CX “25kph” / Intube battery 750Wh/ Purion 200
