Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork Suntour RAIDON
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Prorace 29? Supreme 5 Alloy Disc, Boost, Pressfit, Ta 12x148, Int Brake RR
Suspension Fork
Suntour Raidon 32 RLR DS 15x110 100mm 29"
Drivetrain
Rear Derailleur
Shimano Deore RD-M6100, 12s
Cassette
Shimano Deore CS-M6100 10-51T 12s
Crank
Shimano Deore FC-M5100 32T 170mm (XS/S), 175mm (M, L, XL)
Bottom Bracket
Shimano Press Fit MTB 92
Chain
Shimano Deore 12s (CN-M6100)
Pedals
NW 91K steel cage
Wheels
Rims
Rodi Ryot 25x622, 32H anodized eyelets
Tires
WTB Ranger TCS Light 29x2.25 Tubeless
Brakes
Brakes
Shimano SMRT30 180mm / 160mm Center Lock
Brake Levers
Shimano MT401
Cockpit
Stem
Lapierre 7050 alloy, 7°, Ø: 31.8mm, L: 60mm (XS,S), 70mm (M,L), 80mm (XL)
Handlebar
Lapierre alloy 6061 Top flat, Width: 720mm, Ø: 31.8mm
Grips
Lapierre by Herrmans DD30B
Seat
Saddle
Lapierre XC Saddle
Seatpost
Lapierre alloy, Ø: 27.2mm, L: 400mm
