Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Judy Gold RL
-
Groupset NX Eagle, SX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Prorace 29” Supreme 5 alloy Disc, boost, pressfit, Thru axle 12x148mm, internal brake RR
Suspension Fork
RockShox Judy Gold RL Remote 29'' 15x110 100mm 51mm offset
Drivetrain
Rear Derailleur
SRAM NX Eagle 12spd
Shift Levers
SRAM NX Eagle 12spd
Cassette
SRAM PG1210 Eagle 11-50T 12s
Crank
SRAM SX Eagle DUB 32T 170mm (S) , 175mm (M, L, XL)
Bottom Bracket
SRAM Dub Pressfit 92
Chain
SRAM SX Eagle 12s
Pedals
NW 91K Steel cage
Wheels
Rims
Rodi Tryp25 25x622, 32H Black Anod
Tires
Maxxis Rekon Race EXO TR 29x2.35 120 TPI
Brakes
Brakes
Shimano SMRT30 180mm/160mm Center Lock
Brake Levers
Shimano MT401 2 Pistons
Cockpit
Stem
Lapierre 7050 alloy, 7°, Ø: 31.8mm, L: 60mm (XS,S), 70mm (M,L), 80mm (XL)
Handlebar
Lapierre alloy 6061 Top flat, Width: 720mm, Ø: 31.8mm
Grips
Lapierre by Herrmans
Seat
Saddle
Lapierre XC Saddle
Seatpost
Lapierre Alloy Ø: 27.2mm L: 400mm
