Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork Fox Performance Float 32
-
Groupset X01 Eagle, GX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Prorace 29” carbon, pressfit, boost, Thru axle 12x148mm
Suspension Fork
Fox 32 Float SC Performance 29’’ 15x110, 100mm travel, Grip, Push-Lock, 44mm offset + FOX 2-pos Remote
Drivetrain
Rear Derailleur
SRAM X01 Eagle, 12s
Shift Levers
SRAM GX Eagle Lunar 12s
Cassette
SRAM PG1230 Eagle 11-50 12spd
Crank
SRAM GX Eagle Boost DUB Lunar 32T 170mm (S) , 175mm (M, L, XL)
Bottom Bracket
SRAM DUB PF 92 MTB Wide
Chain
SRAM GX Eagle 12s
Pedals
NW 91K Steel cage
Wheels
Rims
DT Swiss X1900 SPLINE® 622x25c, Shimano Forged ASL Driver
Tires
Maxxis Rekon Race EXO TR 29x2.35 60 TPI
Brakes
Brakes
SRAM Centerline 180mm/160mm 6-bolt
Brake Levers
SRAM LEVEL TL Gloss Black 2 pistons
Cockpit
Stem
Lapierre AL6061 alloy, -6°, Ø: 31.8mm, L: 60mm (S,M), 70mm (L,XL)
Handlebar
Lapierre alloy 6061 Top flat, Width: 740mm, Ø: 31.8mm
Grips
Lapierre grips anodized, S/M: small diameter, L/XL: large diameter
Seat
Saddle
Fizik Argo Vento X 140mm
Seatpost
Lapierre Alloy Ø: 27.2mm L: 400mm
